- Page 1 VCC-SXCXP3M Rev. 905-0049-00 English CoaXPress I/F 1.3M CMOS B/W Camera VCC-SXCXP3M Product Specifications & Operational Manual CIS Corporation ©2017 CIS Corporation. All rights reserved.
-
Page 2: Table Of Contents
Trigger Mode Operation and Burst Mode Operation Outline ............20 Trigger Mode ........................... 21 Burst Mode ..........................22 Index Mode ..........................23 Settings for Sequence Control ....................24 Sequence Status Information ....................25 10. Factory Settings ........................... 26 ©2017 CIS Corporation. All rights reserved. - Page 3 VCC-SXCXP3M Rev. 905-0049-00 11. Dimensions ............................27 11.1 Optical Axis Accuracy......................27 11.2 Camera Dimensions ....................... 28 12. Case for Indemnity (Limited Warranty) ....................29 13. Product Support ..........................29 ©2017 CIS Corporation. All rights reserved.
-
Page 4: Handling Precautions
Do not disassemble the camera. The camera once disassembled shall be out of warranty. Product Outline VCC-SXCXP3M is a CoaXPress interfaced small B/W camera utilizing a 1/2 type, 1.3M pixels CMOS image sensor. Features □ 29mm x 29mm x 29mm cubic in size □... -
Page 5: Specifications
F1.4 0.98 lx (Shutter 1/300(s), Gain 18dB) (9) Pixel Defect Correction Corrected at Ex-factory (10) Gain Variable Range x1～x8 (0dB～18dB) [Guaranteed range] ※based on CIS standard. (11) Shutter Global Shutter (12) Shutter Speed Preset : 1/10000, 1/5000, 1/2500, 1/1200, 1/600, 1/300, 1/150, 1/100 [us] Manual : 100[us]～approx. -
Page 6: Camera Output Signal Specifications
With register settings, FVAL, LVAL, 1 can be output. Uplink Trigger 5V output (After decode) Spectral Response ※The lens characteristic and the illuminant characteristics are excluded. ※Please refer to the data for Mono below. ©2017 CIS Corporation. All rights reserved. -
Page 7: External Connector Pin Assignment
6 pins Circular Connector (SNH-8-6(RPCB) SamWoo Electronics) Pin No. Signals Note SIGNAL_OUT The output of the selected signal TRIGGER_IN Trigger input Conduction with camera casing ※NC means Non-Connection. Do not connect anything to the terminal. ©2017 CIS Corporation. All rights reserved. -
Page 8: 3Pin Signal_Out Circuit
If you wish to save the setting values, execute UserSetSave. Doing so, the setting values shall be saved in the camera internal ROM. Even when the camera power is turned OFF, the saved settings hall be reflected when the camera is turned on next time. ©2017 CIS Corporation. All rights reserved. -
Page 9: Camera Operational Mode
This command is to generate a trigger in the camera and capture image for 1 frame. Please note that the trigger timing is not so accurate like the one generated by TriggerSource. The Acquisition Control mode which can be used are only TriggerSelectorAndActivation --- FrameStartRisingEdge mode. ©2017 CIS Corporation. All rights reserved. -
Page 10: Internal Sync Mode (Free Run Mode)
“L”, video output from the camera might be stopped. In such case or when proper image data cannot be output, execute “SensorReset” command after trigger input is stopped to re-start camera operation. ※ In case of when camera does not start operating, please reboot the camera. Device Control (Execute) SensorReset ©2017 CIS Corporation. All rights reserved. - Page 11 Video Out Exposure Out Exposure time Image Image Cxp Stream Idle Stream data Idle Stream data Idle Header Header LVAL FVAL Trigger input forbidden period Readout time Exposure delay time (A) Exposure delay time (B) ©2017 CIS Corporation. All rights reserved.
- Page 12 Effective Line Effective Line Video Out Exposure Out Exposure time Image Image Cxp Stream Idle Stream data Idle Stream data Idle Header Header LVAL FVAL Readout time Exposure delay time (A) Exposure delay time (B) ©2017 CIS Corporation. All rights reserved.
-
Page 13: Function Settings
When a preset value is set, it will be reflected to manual setting gain. PresetGainX Magnification Decibel equivalent Gain_x1 Gain_x1_5 x1.5 3.5dB Gain_x2 Gain_x3 9.5dB Gain_x4 12dB Gain_x6 15.6dB Gain_x8 18dB ・Manual gain (Gain) Any preferred values from x1 to x32 can be set per x0.25. ©2017 CIS Corporation. All rights reserved. -
Page 14: Shutter
3595 3595 8865 4313 3595 ROIQuickChangePattern4 4936 2347 2347 5540 2649 2347 ROIQuickChangePattern5 3478 1622 1622 3649 1704 1622 8Bit 10Bit CXP1 CXP2 CXP3 CXP1 CXP2 CXP3 Subsampling 3460 1630 1580 3640 1720 1630 ©2017 CIS Corporation. All rights reserved. -
Page 15: Roi (Region Of Interest)
536.7 10bi 257.1 514.2 536.7 The following information for the selected ROI area can be read out. ・ ImageFormatControl Width Height OffsetX OffsetY ROI area is the centered cut of the image sensor. ・ ©2017 CIS Corporation. All rights reserved. -
Page 16: Sub-Sampling
533.7 508.6 CXP-3 533.7 533.7 Defective Pixel Correction CIS compensates the noticeable CMOS pixel defects found at the shipping inspection prior to our shipment. Defective pixel correction can be set to OFF. AnalogControl True DefectivePixelCorrection False ©2017 CIS Corporation. All rights reserved. -
Page 17: Shading Correction
8 bit output, and it changes by approx. 1.0 at 10 bit output. When the lower values than the initial value are set, saturation level would not achieve to the maximum value for ・ output range. ©2017 CIS Corporation. All rights reserved. -
Page 18: Test Pattern
ROI or sub-sampling was changed with keep grabbing video output. This is because error indication status was kept since those errors occurred. To restore this to normal LED lighting status, reboot the camera, or execute Device Control—SensorReset ©2017 CIS Corporation. All rights reserved. -
Page 19: Camera Timing Output
The user defined device name up to 16 characters can be set to the camera. Execute “UserSetSave” to save it to EEPROM in the camera. Execute “UserSetDefault” if you wish to restore it to the factory setting. ※ This is the resister area for up to 16byte. English single byte characters shall be input. ©2017 CIS Corporation. All rights reserved. -
Page 20: Sequence Control Function
This is to set the start operation of sequence mode. By setting preferred SequenceActivation from Off, it will be standing by for a trigger. (6) Sequence control operation starts by inputting a trigger to start sequence function. ©2017 CIS Corporation. All rights reserved. -
Page 21: Trigger Mode Operation And Burst Mode Operation Outline
Gain Gain Gain Index0 Index1 Index2 Index3 Index #4 Index #5 Applying param Applying param Applying param Applying param Applying param Applying param Param#0 Param#1 Param#4 Param#8 Param#0 Param#1 1023 ActiveIndexNumber IndexLoopCount SequencerLoopCount ParameterIndexNumber ©2017 CIS Corporation. All rights reserved. -
Page 22: Trigger Mode
FrameStartLevelHigh ・ FrameStartLevelLow. Exposure time for each frame (① and ②) is the pulse width of the trigger. ・ When the image output for the sequence Loop count is completed, sequence operation ends ・ ©2017 CIS Corporation. All rights reserved. -
Page 23: Burst Mode
When the image output for the sequence Loop count is completed, sequence operation ends. ・ (3). Resister Start Sequence operation starts at the same time when SequencerActivation is turned off and FrameBurstStartSoftware is ・ set. To restart burst mode operation, turn off SequencerActivation OFF once. ※ ©2017 CIS Corporation. All rights reserved. -
Page 24: Index Mode
※ As to the timing to issue IndexSelectorModeIndexNumber command, input a trigger pulse when ACK is responded after IndexSelectorModeIndexNumber is issued, to make sure the specified parameter set is to be reflected to the next frame. ©2017 CIS Corporation. All rights reserved. -
Page 25: Settings For Sequence Control
Loop count for whole sequence. 0: infinity ActiveIndexNumber The largest Index number to execute. IndexSelectorModeIndexNumber The Index number to use for Index Mode. ParameterIndexNumber Index0-7 Parameter number of Index 0-7. IndexLoopCount IndexCount0-7 Repeating count of each Index 0-7. ©2017 CIS Corporation. All rights reserved. -
Page 26: Sequence Status Information
The position to indicate the status information can be selected out of four positions as below, and the information is to be embedded into 5 pixels. TopLeft TopRight Pix0 Pix1 Pix2 Pix3 Pix4 Effective Image BottomLeft BottmRight ©2017 CIS Corporation. All rights reserved. -
Page 27: Factory Settings
The same value as the Index number Index0Count～Index7Count All 1 SequencerLoopCount ActiveIndexModeIndexNumber SequencerExposureTime 1000.0 (Selector 0-7) SequencerGain (Selector 0-7) TransportLayer CxpLinkConfiguration CXP_X1 ※ Factory setting values are the same as the one for UserSetDefault command. ©2017 CIS Corporation. All rights reserved. -
Page 28: Dimensions
VCC-SXCXP3M Rev. 905-0049-00 11. Dimensions 11.1 Optical Axis Accuracy ©2017 CIS Corporation. All rights reserved. -
Page 29: Camera Dimensions
VCC-SXCXP3M Rev. 905-0049-00 11.2 Camera Dimensions ©2017 CIS Corporation. All rights reserved. -
Page 30: Case For Indemnity (Limited Warranty)
CIS Corporation, at its option, repairs or replaces it at no charge to you. Products out of warranty period will be subject to charge. CIS repairs the products as long as it is repairable. CIS shall be exempted from taking responsibility and held harmless for damages or losses incurred by the following cases.
