CIS VCC-SXCXP3R Product Specification & Operational Manual

Coaxpress i/f 1.3m cmos color camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VCC-SXCXP3R
Rev. 905-0050-00
English
CoaXPress I/F
1.3M CMOS Color Camera
VCC-SXCXP3R
Product Specifications
& Operational Manual
CIS Corporation
©2017 CIS Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCC-SXCXP3R and is the answer not in the manual?

Questions and answers

Related Manuals for CIS VCC-SXCXP3R

Summary of Contents for CIS VCC-SXCXP3R

  • Page 1 VCC-SXCXP3R Rev. 905-0050-00 English CoaXPress I/F 1.3M CMOS Color Camera VCC-SXCXP3R Product Specifications & Operational Manual CIS Corporation ©2017 CIS Corporation. All rights reserved.

  • Page 2: Table Of Contents

    Index Mode ............................24 Settings for Sequence Control ....................... 25 Sequence Status Information ........................ 27 10. Factory Settings............................. 28 11. Dimensions ..............................29 11.1 Optical Axis Accuracy ........................29 11.2 Camera Dimensions ........................30 ©2017 CIS Corporation. All rights reserved.
  • Page 3 VCC-SXCXP3R Rev. 905-0050-00 12. Case for Indemnity (Limited Warranty) ......................31 13. Product Support ............................31 ©2017 CIS Corporation. All rights reserved.

  • Page 4: Handling Precautions

    Do not disassemble the camera. The camera once disassembled shall be out of warranty.  Product Outline VCC-SXCXP3R is a CoaXPress interfaced small color camera utilizing a 1/2 type, 1.3M pixels CMOS image sensor. Features □ 29mm x 29mm x 29mm cubic in size □...

  • Page 5: Specifications

    6 directions. (Without packaging) (23) Operational Environment Operation -5 ～ +45℃ Humidity with no condensation guaranteed 20 ~ 80%RH (24) Storage Environment Storage Temperature: -25 ~ + 60℃, Hum idity: 20 ~ 80% RH with no condensation. ©2017 CIS Corporation. All rights reserved.

  • Page 6: Camera Output Signal Specifications

    With register settings, FVAL, LVAL, 1 can be output. Uplink Trigger 5V output (After decode) Spectral Response ※The lens characteristic and the illuminant characteristics are excluded. ※Please refer to the data for Mono below. ©2017 CIS Corporation. All rights reserved.

  • Page 7: External Connector Pin Assignment

    6 pins Circular Connector (SNH-8-6(RPCB) SamWoo Electronics) Pin No. Signals Note SIGNAL_OUT The output of the selected signal TRIGGER_IN Trigger input Conduction with camera casing ※NC means Non-Connection. Do not connect anything to the terminal. ©2017 CIS Corporation. All rights reserved.

  • Page 8: How To Save And Initialize The Settings

    If you wish to save the setting values, execute UserSetSave. Doing so, the setting values shall be saved in the camera internal ROM. Even when the camera power is turned OFF, the saved settings shall be reflected when the camera is turned on next time. ©2017 CIS Corporation. All rights reserved.

  • Page 9: Camera Operational Mode

    This command is to generate a trigger in the camera and capture image for 1 frame. Please note that the trigger timing is not so accurate like the one generated by TriggerSource. The Acquisition Control mode which can be used are only TriggerSelectorAndActivation --- FrameStartRisingEdge mode. ©2017 CIS Corporation. All rights reserved.

  • Page 10: Internal Sync Mode (Free Run Mode)

    “L”, video output from the camera might be stopped. In such case or when proper image data cannot be output, execute “SensorReset” command after trigger input is stopped to re-start camera operation. ※ In case of when camera does not start operating, please reboot the camera. Device Control (Execute) SensorReset ©2017 CIS Corporation. All rights reserved.
  • Page 11 Video Out Exposure Out Exposure time Image Image Cxp Stream Idle Stream data Idle Stream data Idle Header Header LVAL FVAL Trigger input forbidden period Readout time Exposure delay time (A) Exposure delay time (B) ©2017 CIS Corporation. All rights reserved.
  • Page 12 Effective Line Effective Line Video Out Exposure Out Exposure time Image Image Cxp Stream Idle Stream data Idle Stream data Idle Header Header LVAL FVAL Readout time Exposure delay time (A) Exposure delay time (B) ©2017 CIS Corporation. All rights reserved.

  • Page 13: Function Settings

    When a preset value is set, it will be reflected to manual setting gain. PresetGainX Magnification Decibel equivalent Gain_x1 Gain_x1_5 x1.5 3.5dB Gain_x2 Gain_x3 9.5dB Gain_x4 12dB Gain_x6 15.6dB Gain_x8 18dB ・Gain: Manual gain Any preferred values from x1 to x32 can be set per x0.25. ©2017 CIS Corporation. All rights reserved.

  • Page 14: Shutter

    3595 3595 8865 4313 3595 ROIQuickChangePattern4 4936 2347 2347 5540 2649 2347 ROIQuickChangePattern5 3478 1622 1622 3649 1704 1622 8Bit 10Bit CXP1 CXP2 CXP3 CXP1 CXP2 CXP3 Subsampling 3460 1630 1580 3640 1720 1630 ©2017 CIS Corporation. All rights reserved.

  • Page 15: Roi (Region Of Interest)

    536.7 10bi 257.1 514.2 536.7 The following information for the selected ROI area can be read out. ・ ImageFormatControl Width Height OffsetX OffsetY ROI area is the centered cut of the image sensor. ・ ©2017 CIS Corporation. All rights reserved.

  • Page 16: Sub-Sampling

    533.7 508.6 CXP-3 533.7 533.7 Defective Pixel Correction CIS compensates the noticeable CMOS pixel defects found at the shipping inspection prior to our shipment. Defective pixel correction can be set to OFF. AnalogControl True DefectivePixelCorrection False ©2017 CIS Corporation. All rights reserved.

  • Page 17: Shading Correction

    8 bit output, and it changes by approx. 1.0 at 10 bit output. When the lower values than the initial value are set, saturation level would not achieve to the maximum value for ・ output range. ©2017 CIS Corporation. All rights reserved.

  • Page 18: Test Pattern

    ROI or sub-sampling was changed with keep grabbing video output. This is because error indication status was kept since those errors occurred. To restore this to normal LED lighting status, reboot the camera, or execute Device Control—SensorReset ©2017 CIS Corporation. All rights reserved.

  • Page 19: Camera Timing Output

    The user defined device name up to 16 characters can be set to the camera. Execute “UserSetSave” to save it to EEPROM in the camera. Execute “UserSetDefault” if you wish to restore it to the factory setting. ※ This is the resister area for up to 16byte. English single byte characters shall be input. ©2017 CIS Corporation. All rights reserved.

  • Page 20: White Balance

    BalanceWhiteGainRed 0 – 8.0 BalanceWhiteGainBlue 0 – 8.0 As to BalanceWhiteGainRed/Blue, the values for OnePush execution shall be reflected first, when BalanceWhiteControl is selected to Manual. And, any preferred values can be input later. ©2017 CIS Corporation. All rights reserved.

  • Page 21: Sequence Control Function

    This is to set the start operation of sequence mode. By setting preferred SequenceActivation from Off, it will be standing by for a trigger. (6) Sequence control operation starts by inputting a trigger to start sequence function. ©2017 CIS Corporation. All rights reserved.

  • Page 22: Trigger Mode Operation And Burst Mode Operation Outline

    Gain Gain Gain Index0 Index1 Index2 Index3 Index #4 Index #5 Applying param Applying param Applying param Applying param Applying param Applying param Param#0 Param#1 Param#4 Param#8 Param#0 Param#1 1023 ActiveIndexNumber IndexLoopCount SequencerLoopCount ParameterIndexNumber ©2017 CIS Corporation. All rights reserved.

  • Page 23: Trigger Mode

    ・ FrameStartLevelLow. Exposure time for each fram e (① and ②) is the pulse width of the trigger. ・ When the image output for the sequence Loop count is completed, sequence operation ends. ・ ©2017 CIS Corporation. All rights reserved.

  • Page 24: Burst Mode

    When the image output for the sequence Loop count is completed, sequence operation ends. ・ (3). Resister Start Sequence operation starts at the same time when SequencerActivation is turned off and FrameBurstStartSoftware is ・ set. To restart burst mode operation, turn off SequencerActivation OFF once. ※ ©2017 CIS Corporation. All rights reserved.

  • Page 25: Index Mode

    ※ As to the timing to issue IndexSelectorModeIndexNumber command, input a trigger pulse when ACK is responded after IndexSelectorModeIndexNumber is issued, to make sure the specified parameter set is to be reflected to the next frame. ©2017 CIS Corporation. All rights reserved.

  • Page 26: Settings For Sequence Control

    Set to start index mode. ・ FrameBurstStartEdge: Set to start burst mode with edge control. ・ FrameBurstStartLevel: Set to start burst mode with High level control. ・ FrameBurstStartSoftware: Set to start burst mode with register start. ・ ©2017 CIS Corporation. All rights reserved.
  • Page 27 Seven parameter sets are prepared. By changing the number of SequencerParameterSetSelector, parameter set will be replaced. Even if the parameter number is changed, the set data can be kept saved. SequencerParameterSetSelector Parameter Set 0～7 SetConfiguration ・ SequencerExposureTime Exposure Time SequencerGain Gain ©2017 CIS Corporation. All rights reserved.

  • Page 28: Sequence Status Information

    In case of 10bit video output, 2 bit on LSB side shall be always “00”. pix0 Index Number[3:0] “0000” “00” pix1 Repeating Count [7:0] “00” pix2 “000000” Repeating Count “00” [9:8] pix3 Loop Count [7:0] “00” pix4 “000000” Loop Count [9:8] “00” ©2017 CIS Corporation. All rights reserved.

  • Page 29: Factory Settings

    The same value as the Index number Index0Count～Index7Count All 1 SequencerLoopCount ActiveIndexNumber ActiveIndexModeIndexNumber SequencerExposureTime 1000.0 (Selector 0-7) SequencerGain (Selector 0-7) TransportLayer CxpLinkConfiguration CXP_X1 Factory setting values are the same as the one for UserSetDefault command. ※ ©2017 CIS Corporation. All rights reserved.

  • Page 30: Dimensions

    VCC-SXCXP3R Rev. 905-0050-00 11. Dimensions 11.1 Optical Axis Accuracy ©2017 CIS Corporation. All rights reserved.

  • Page 31: Camera Dimensions

    VCC-SXCXP3R Rev. 905-0050-00 11.2 Camera Dimensions ©2017 CIS Corporation. All rights reserved.
  • Page 32 CIS Corporation, at its option, repairs or replaces it at no charge to you. Products out of warranty period will be subject to charge. CIS repairs the products as long as it is repairable. CIS shall be exempted from taking responsibility and held harmless for damages or losses incurred by the following cases.
