CIS VCC-5CL4M Product Specification & Operational Manual

Camera link i/f 5.01m pixels cmos b/w camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VCC-5CL4M
Rev.905-0060-04
Camera Link I/F
5.01M Pixels CMOS B/W Camera
VCC-5CL4M
Product Specifications
& Operational Manual
CIS Corporation
©2016 CIS Corporation. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VCC-5CL4M and is the answer not in the manual?

Questions and answers

Related Manuals for CIS VCC-5CL4M

Summary of Contents for CIS VCC-5CL4M

  • Page 1 VCC-5CL4M Rev.905-0060-04 Camera Link I/F 5.01M Pixels CMOS B/W Camera VCC-5CL4M Product Specifications & Operational Manual CIS Corporation ©2016 CIS Corporation. All rights reserved.

  • Page 2: Table Of Contents

    11.1. SAVE User Data ............................. 31 11.2. Reading Out of User Data ........................31 Factory Settings ............................. 32 Sensor Optical Axis Accuracy .......................... 33 Dimensions ..............................34 Case for Indemnity (Limited Warranty) ......................35 ©2016 CIS Corporation. All rights reserved.
  • Page 3 VCC-5CL4M Rev.905-0060-04 CMOS Pixel Defect ............................35 Product Support ............................35 Ordering Information ............................. 35 ©2016 CIS Corporation. All rights reserved.

  • Page 4: Handling Precautions

    The rising time of camera power supply voltage shall be less than +10V, Max 60ms. Please avoid noises like  chattering when rising. Power supply voltage [V] 電源 電圧 立 ち 上 がり 時間[ ms] Voltage rising time [ms] ©2016 CIS Corporation. All rights reserved.

  • Page 5: Product Outline

    Rev.905-0060-04 Product Outline VCC-5CL4M is a Camera Link interfaced and 5M resolution, small industrial B/W camera module. 5.01M pixels, 2/3 type (diagonal length 11.1mm) B/W CMOS sensor is utilized. Entire pixels can be read out at 1/114s with Full configuration output.

  • Page 6: Specifications

    : 20 ~ 200 Hz Frequency : X,Y, and Z 3 directions Direction : 120min for each direction Testing time Shock No malfunction shall be occurred with 980m/s (100G) for ±X,±Y, and ±Z, 6 directions. ©2016 CIS Corporation. All rights reserved.

  • Page 7: Camera Input And Output Signals Specifications

    00Fh. (Condition: Gain 0dB) +5.0V( VCC) 100Ω FVAL Output LVAL Output DVAL Output HD74LV1GT32 ACME(RENESAS) Exposure Output Voh:3.8V(Min) Vol:0.55V( Max) 100Ω Trigger Input HD74LV1GT14 ACME(RENESAS) Vt-:0.5(Min) Vt+:1.9V(Max) IO Interface of 12pins Circular connector at rear ©2016 CIS Corporation. All rights reserved.

  • Page 8: Cmos Spectral Response

    VCC-5CL4M Rev.905-0060-04 4.3. CMOS Spectral Response ※The lens characteristics and illuminant characteristics are excluded. ©2016 CIS Corporation. All rights reserved.

  • Page 9: Video Output Format

    (1) 2Tap Base configuration mode : 28fps 2448pixels ・・・ (2) 3Tap Base configuration mode : 42fps 2448pixels ・・・ (3) 4Tap Medium configuration mode : 57 fps 2448pixels ・・・ (4) 8Tap Full , 8tap10bit configuration mode : 114fps 2448pixels ・・・ ©2016 CIS Corporation. All rights reserved.

  • Page 10: Camera Function Settings

    Output image horizontal flip Normal When operating the cursor is reset to Horizontal flip (0, 0).) Output image vertical flip Normal When operating the cursor is reset to Vertical flip (0, 0).) Defective pixel correction ©2016 CIS Corporation. All rights reserved.
  • Page 11 Deletion of defect pixels by users 2 parameters Delete the defective pixels specified with (x, y). Complete deletion of defect pixels 1 (fixed) Delete all the defect pixels detected and registered by the by users user. ©2016 CIS Corporation. All rights reserved.
  • Page 12 User data settings 2 parameters Set any data for the user area (32 byte). All 0xFF at Save with SAVE command. ex-factory ※Do not set any address or data other than specified the above. ©2016 CIS Corporation. All rights reserved.

  • Page 13: The List Of Preset Shutter

    We recommend you to evaluate it first to use. ※ When camera mode (Tap mode) is changed, please re-set other functions, too. ※ When gain is set to over +36dB, image quality deterioration is inevitable. Please evaluate first. ©2016 CIS Corporation. All rights reserved.

  • Page 14: External Connector Pin Assignment

    VCC-5CL4M Rev.905-0060-04 External Connector Pin Assignment 6.1. 12pins Circular Connector HR10-10R-12PA(73) (HIROSE) or equivalent Pin No. Description Power input (DC+12V) LVAL output FVAL output Exposure output DVAL output TRIGGER inputs ©2016 CIS Corporation. All rights reserved.

  • Page 15: Camera Link Connector 12226-1100-00Pl (Sumitomo 3M)

    (2) CL・・・To be selected when Non-PoCL frame grabber board is used. Please make sure that power is OFF when changing the switch settings. If the switch setting was changed while power is ON, it may cause malfunction or damages to the camera. ©2016 CIS Corporation. All rights reserved.

  • Page 16: Timing Chart

    Effective Line Video Out FVAL Out LVAL Out DVAL Out V Blanking :46H Effective Line : 2048H 1Frame = 2094H 40Ｈ SP Out(Exposure Out) Exposure Time 1H = 16.56us 2Tap Base configuration mode: 28fps ©2016 CIS Corporation. All rights reserved.

  • Page 17: Horizontal Synchronous Signals Timing (3Tap Base Configuration Mode)

    Effective Line Video Out FVAL Out LVAL Out DVAL Out V Blanking :46H Effective Line : 2048H 1Frame = 2094H 40Ｈ SP Out(Exposure Out) Exposure Time 1H = 11.04us 3Tap Base configuration mode: 42fps ©2016 CIS Corporation. All rights reserved.

  • Page 18: Horizontal Synchronous Signals Timing (4Tap Medium Configuration Mode)

    Effective Line Video Out FVAL Out LVAL Out DVAL Out V Blanking :46H Effective Line : 2048H 1Frame = 2094H 40Ｈ SP Out(Exposure Out) Exposure Time 1H = 8.28us 4Tap Medium configuration mode: 57fps ©2016 CIS Corporation. All rights reserved.

  • Page 19: Horizontal Synchronous Signals Timing (8Tap Configuration Mode)

    Effective Line Effective Line Video Out FVAL Out LVAL Out DVAL Out V Blanking :46H Effective Line : 2048H 1Frame = 2094H 40Ｈ SP Out(Exposure Out) Exposure Time 1H = 4.17us 8Tap configuration mode: 114fps ©2016 CIS Corporation. All rights reserved.

  • Page 20: Fixed Trigger Shutter Mode

    Note that a trigger shorter than 1 frame cycle shall not be used. Effective Line Effective Line Exposure Time Effective Line : 2048H Exposure Time Delay Trigger input ignore period TRIG IN Exposure Out (SP Out) Exposure time delay ©2016 CIS Corporation. All rights reserved.

  • Page 21: Fast Fixed Trigger Shutter Mode

    Next trigger rise prohibited period : 2110H Exposure Out Exposure Time LVAL Out DVAL Out FVAL Out Effective Line : 2048H Exposure Time Delay Trigger input ignore period TRIG IN Exposure Out (SP Out) Exposure time delay ©2016 CIS Corporation. All rights reserved.

  • Page 22: Pulse Width Trigger Shutter Mode

    Triggers can be accepted while outputting video output images. However, please be noted that a trigger signal to □ start the next video outputting before completion of outputting the prior images should not be input. (Refer to (A) the drawing below). ©2016 CIS Corporation. All rights reserved.

  • Page 23: Fast Pulse Width Trigger Shutter Mode

    There is an exposure time period for approx. 13.73μs at the edge right after exposure output. □ Trigger input during exposure time shall be ignored in the camera. (Refer to (A) in the drawing below). ©2016 CIS Corporation. All rights reserved.
  • Page 24 Exposure Out Exposure Time LVAL Out DVAL Out FVAL Out Effective Line : 2048H Exposure Time Delay① Exposure Time Delay② Trigger input ignore period TRIG IN ① ② Exposure Out (SP Out) Exposure time delay ©2016 CIS Corporation. All rights reserved.

  • Page 25: Partial Scan Mode

    Partial effective lines 1 + Partial effective lines 2 + ・・・ + Partial effective lines 8 Note that Sum total of partial effective line numbers from 1~8 (except V blanking lines) has to be less than 2048. V blanking lines at partial mode is 46H. ©2016 CIS Corporation. All rights reserved.
  • Page 26 *Especially at fixed trigger shutter mode and pulse width trigger shutter mode, input a dummy trigger first, and use the next trigger as an actual video signal. ©2016 CIS Corporation. All rights reserved.

  • Page 27: Remote Communication Function

    [¥r] [¥n] [Linefeed] [sp]=Space(0x20) [Returned value] >[sp] [Prompt + Space] 【Example of Set Command】 To set 30 to the address 21 [Send] SU[sp]21[sp]30[¥r]or[¥n] [Returned value] [¥r] [¥n] [Linefeed] [Returned value] >[sp] [Prompt + Space] ©2016 CIS Corporation. All rights reserved.
  • Page 28 Input “INIT” to restore to the initial settings. (Not saved at this point). (7) Data Save Input “SAVE” to save the camera settings [Returned value] [¥r] [¥n] [Linefeed] [Returned value] >[sp] [Prompt + Space] ©2016 CIS Corporation. All rights reserved.

  • Page 29: Pixel Defect Correction

    (2) If no effective pixel exists up next, down next, right next, or left next to the pixel to be corrected, this pixel can be registered but cannot be corrected. For example, when X1, X2, X3, and X4 are already registered as defected pixels, X can be added to be registered but it cannot be corrected. ©2016 CIS Corporation. All rights reserved.
  • Page 30 This is to delete all defected pixels data detected and registered by the users, with Address 100 and Address 101. Please execute this when you wish to redo your detection and registration from the beginning, or when you wish to restore all the registration to the factory settings. SU 103 1 to execute. ©2016 CIS Corporation. All rights reserved.
  • Page 31 To show the coordinate points of out of the area, execute parameter 1 or parameter 2. These points  would be shown as minus coordinate or as the one of the out of image size. ©2016 CIS Corporation. All rights reserved.

  • Page 32: User Data Save/Readout Function

    Data are shown with hexadecimal with space partitions. When data count more than the address are specified, error would occur and it would not be read out. 【Send】 GU[sp]200[sp] Readout Address[sp]Read out Count 【Returned value】 0xnn[sp]0xnn[sp]0xnn[sp][¥r][¥n] 【Returned value】>[sp] ©2016 CIS Corporation. All rights reserved.

  • Page 33: Factory Settings

    Normal Vertical flip of the output image Normal Defective pixel correction Serial communication baud rate 9600 baud Gain Shutter Vertical partial mode OFF (2048 lines) Factory setting for rear switch Power selection CL side ©2016 CIS Corporation. All rights reserved.

  • Page 34: Sensor Optical Axis Accuracy

    VCC-5CL4M Rev.905-0060-04 13. Sensor Optical Axis Accuracy ©2016 CIS Corporation. All rights reserved.

  • Page 35: Dimensions

    VCC-5CL4M Rev.905-0060-04 14. Dimensions ©2016 CIS Corporation. All rights reserved.

  • Page 36: Case For Indemnity (Limited Warranty)

    CIS Corporation, at its option, repairs or replaces it at no charge to you. Products out of warranty period will be subject to charge. CIS repairs the products as long as it is repairable. CIS shall be exempted from taking responsibility and held harmless for damages or losses incurred by the following cases.
