Replacing the Remote Display Assembly,
With the old assembly removed, the remote box is ready for the new remote display assembly.
Installing the
New Remote
1.
Orient the new remote display assembly so that the graphic overlay and LCD screen face
Display
downward, and the bottom of the assembly is set against the bottom edge of the remote box. (see
Assembly
Figure 8)
2.
Depress the latches at the bottom of the door assembly and hook the door onto the swivel standoffs
extending in from the side panels of the bay (see Figure 8).
3.
Loop the ring at the end of each grounding strap to the corresponding studs extending from the
back of the door assembly. Fasten each strap to the stud with the supplied #8 washer and nut.
4.
Connect the harness 734-008 from either P7 or P9 on the Flexible User Interface controller card to
P2 on the TIC. Dress the harness so that there will be no abrasion or binding when the door closes.
5.
Set SW-1 on the Flexible User Interface controller card (see Figure 8) to the address assigned in the
FACP Programmer.
6.
Close the panel assembly, and apply power to the system.
continued
11
