Axiom AX16CL User Manual

High output column array loudspeaker
Hide thumbs Also See for AX16CL:
Table of Contents

Advertisement

Quick Links

Download this manual
AX16CL - AX8CL
High Output Column Array Loudspeaker
USER MANUAL
revision 2021-12-13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AX16CL and is the answer not in the manual?

Questions and answers

Related Manuals for Axiom AX16CL

Summary of Contents for Axiom AX16CL

  • Page 1 AX16CL - AX8CL High Output Column Array Loudspeaker USER MANUAL revision 2021-12-13...
  • Page 2 IMPORTANT SAFETY INSTRUCTIONS Watch for these symbols: The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure, that may be of sufficient magnitude to constitute a risk of electric shock to persons.
  • Page 3 DECLARATION OF CONFORMITY The product is in compliance with: LVD Directive 2014/35/EU, RoHS Directive 2011/65/EU and 2015/863/EU, WEEE Directive 2012/19/EU. LIMITED WARRANTY Proel warrants all materials, workmanship and proper operation of this product for a period of two years from the original date of purchase. If any defects are found in the materials or workmanship or if the product fails to function properly during the applicable warranty period, the owner should inform about these defects the dealer or the distributor, providing receipt or invoice of date of purchase and defect detailed description.

  • Page 4: Table Of Contents

    The AX8CL is a column half-size of the AX16CL, so the two models can be combined together to form a more flexible column array that can be pointed more precisely to the audience.

  • Page 5: Ax16Cl Mechanical Drawing

    AX16CL MECHANICAL DRAWING 15.4 cm 6.06"...

  • Page 6: Ax8Cl Mechanical Drawing

    Foam adapters for stage monitor or frontfill application COVERAX8CL Cover / carrying bag for single AX8CL KPTFAX16CL Floor stand for up to 2 units AX16CL ESO2500LU025 25 cm SPEAKON linking cable 4x4mm KPTSTANDAX16CL Floor stand for up to 2 units AX16CL NL4FX Neutrik Speakon®...

  • Page 7: Rear Panel

    - no connection (pass thru link speakon) WARNING: The maximum quantity of AX16CL that can be linked together depends by the load capacity of the appropriate processed amplifier. When powered from the SW212A subwoofer or from the QC2.4 suggested amplifier, a maximum of four...

  • Page 8: Prediction Software: Ease Focus 3

    As can be seen from the table some combinations of array elements can be used with different presets. For example if you have 3 AX16CL you can use both the 2 x AX16CL preset and the 4 x AX16CL preset, depending on the balance between subwoofer and columns you want to obtain: by choosing 2x there the balance will be shifted towards the high frequencies, while by choosing 4x the balance will be shifted towards the low frequencies.

  • Page 9: Pin Locking And Splay Angles Set Up

    PIN LOCKING AND SPLAY ANGLES SET UP The figure below shows how to insert correctly the locking pin and how to set up the splay angle between loudspeakers. LOCKING PIN INSERTION AX16CL and AX8CL column to column SW212A and AXCL...

  • Page 10: Stacked Installation Using Sw212A Subwoofer As Base

    Always secure ground stacked setups against movement and possible tipping over. • A maximum of 2x AX16CL or 4x AX8CL or 1x AX16CL + 2x AX8CL speakers are allowed to be installed over a SW212A serving as ground support. •...

  • Page 11: Stacked Installation Using Kptstandax16Cl Floor Stand

    • Always secure ground stacked setups against movement and possible tipping over. • A maximum of 2 x AX16CL or 4 x AX8CL or 1x AX16CL + 2x AX8CL speakers are allowed to be installed over a KPTSTANDAX16CL serving as ground support.
  • Page 12 1 - Same as below. 2 - Loosen the knobs (H) and (L). 3 - Place the second column (I). 4 - Insert the front pin (F). 5 - Insert the rear pin (G) in the desired aiming position. 6 - Tighten the knobs (H) and (L).

  • Page 13: Stand

    • Always secure ground stacked setups against movement and possible tipping over. • A maximum of 2 x AX16CL or 4 x AX8CL or 1x AX16CL + 2x AX8CL speakers are allowed to be installed over a KPTFAX16CL serving as ground support.
  • Page 14 1 - Same as below. 2 - Loosen the knobs (H) and (L). 3 - Place the second column (I). 4 - Insert the front pin (F). 5 - Insert the rear pin (G) in the desired aiming position. 6 - Tighten the knobs (H) and (L).

  • Page 15: Stacked Installation With Kptpoleax16Cl Pole Adapter

    • Adjust the feet so to put the KTPFAX16CL perfectly horizontal. Use a spirit level to obtain the best result. • Always secure ground stacked setups against movement and possible tipping over. • A maximum of 1 x AX16CL or 2 x AX8CL speakers are allowed to be installed over a KPTFAX16CL with pole serving as ground support.

  • Page 16: Floor And Front Fill Installation Using Kptfaxcl Foam Stand

    FLOOR AND FRONT FILL INSTALLATION USING KPTFAXCL FOAM STAND WARNINGS: • KPTFAX8CL can be used in front-fill or monitor applications on stage. • The ground where the KPTFAXCL foam stand is placed needs to be stable and compact. • When using this support for frontfill application, place it on a stable surface. If it is placed on a front line subwoofer, it must be secured to it using a strap, because the subwoofer vibrations could cause it to fall to ground.

  • Page 17: Wall Installation Using Kptwax16Cll Brackets

    • Brackets MUST be installed by qualified personnel in accordance with safe installation practices. • A single AX16CL or 2x AX8CL speakers can be installed using the KPTWAX16CLL as top and bottom wall brackets. Column orientation is possible only aiming it at 0°.

  • Page 18: Wall Installation Using Kptwax16Cl And Kptwax16Cll Brackets

    • Brackets MUST be installed by qualified personnel in accordance with safe installation practices. • A maximum of 2 x AX16CL or 1 x AX16CL + 2 AX8CL speakers can be installed using the KPTWAX16CL as top and the KPTWAX16CLL as bottom wall brackets.

  • Page 19: Wall Installation Using Kptwax16Cl Brackets

    • Brackets MUST be installed by qualified personnel in accordance with safe installation practices. • A maximum of 4 x AX16CL speakers can be installed using the KPTWAX16CL as top and bottom wall brackets. 1 - Orientate the bracket then tighten the knobs (A).

  • Page 20: Suspended Installation Using Kptax16Cl Flybar

    Using the KPTAX16CL fly bar it is possible to assemble a suspended and unobtrusive vertical array system with a variable size up to 6 elements of AX16CL, or a combination of AX16CL and AX8CL, without exceeding the 120Kg maximum load capacity. The loudspeakers are linked together in a column using the brackets integrated at each end of the enclosure.
  • Page 21 The following examples show some possible configurations with maximum splay angles: the first use 4 x AX16CL, the second a mixed configuration made with 2 x AX16CL and 4 x AX8CL, the third is made using 8 x AX8CL.
  • Page 22 The following examples shows all the possible connections between the SW212A amplified subwoofer and the AX16CL column speaker, using the PRESETs available in the subwoofer’s DSP. Note that one AX16CL unit correspond to two AX8CL units. SW212A + 1 x AX16CL set preset 1 x AX16CL 4 x 4mm²...
  • Page 23 SW212A + 4 x AX16CL 1+/1- ESO2500LU05 - lenght 0,25m 1+/1- 1+/1- ESO2500LU05 - lenght 0,25m 1+/1- 1+/1- ESO2500LU05 - lenght 0,25m 1+/1- set preset 4 x AX16CL 4 x 4mm² speaker cable 1+/1- 1+/1- ESO2500LU2 - lenght 2m ESO2500LU15 - lenght 15m...
  • Page 24 PROEL S.p.A. (World Headquarters) - Via alla Ruenia 37/43 - 64027 Sant’Omero (Te) - ITALY Tel: +39 0861 81241 Fax: +39 0861 887862 www.axiomproaudio.com...
