SUPPLIED MATERIALS
COLUMN
SPEAKER
ADAPTER
WALL BRACKET
(LIGHT VERSION)
M8 WASHER
M8x16 NUT SCREW
TYPICAL TOP ASSEMBLY
THIS HOLE ALLOWS
THE PASSAGE OF A
SPEAKON CABLE
WARNINGS:
• No hardware is supplied to install the KPTWAX16CLL to the walls: the hardware to be used depends on the wall structure.
Use always the best hardware available, taking in considera�on the whole weight of loudspeakers and accessories.
• Brackets MUST be installed by qualified personnel in accordance with safe installa�on prac�ces.
• A single AX16CL or 2x AX8CL speakers can be installed using the KPTWAX16CLL as top and bo�om wall brackets.
• KPTWAX16CLL can be used also in combina�on with KPTWAX16CL as bo�om bracket for 2x AX16CL speakers.
PROEL S.p.A. - Via alla Ruenia 37/43 - 64027 Sant'Omero (Te) - ITALY Tel: +39 0861 81241 www.axiomproaudio.com
AX16CL/AX8CL WALL BRACKETS
CODE: KPTWAX16CLL
Assembly Instruc�ons
LOCKING PIN
(94SPI10555)
M6 KNOB
LOCKING PIN INSERTION
press and
insert
DIMENSIONS and DRILLING
16.4 cm
6.47"
13.9 cm
5.49"
0° PIN HOLE
8.36 cm
3.29"
release and
lock
0° PIN HOLE
ø 7 mm
0.276"
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Axiom AX16CL
Summary of Contents for Axiom AX16CL
- Page 1 • Brackets MUST be installed by qualified personnel in accordance with safe installa�on prac�ces. • A single AX16CL or 2x AX8CL speakers can be installed using the KPTWAX16CLL as top and bo�om wall brackets. • KPTWAX16CLL can be used also in combina�on with KPTWAX16CL as bo�om bracket for 2x AX16CL speakers.
- Page 2 AX16CL/AX8CL WALL BRACKETS CODE: KPTWAX16CLL Assembly Instruc�ons ASSEMBLY SEQUENCE 60¡* 60¡ CONDITIONS OF USE Proel do not accept any liability for damage caused to third par�es due to improper installa�on, use of non-original spare parts, lack of maintenance, tampering or improper use of this product, including disregard of acceptable and applicable safety standards. Proel strongly recommends that this loudspeaker cabinet be suspended taking into considera�on all current Na�onal, Federal, State and Local...
