Axiom AX6C User Manual

KEY FEATURES
• High Power passive portable Line Array element
• Designed for mobile and installed applications
• Fast, easy-to-use integrated suspension system
• Aluminium frame structure
• Black or white finish
INTRODUCTION
The AX6C Line Array is a passive system equipped with six 3.5" neodymium transducers with waterproof cones, designed for
portable and permanently installed applications where high power and clarity are needed. The aluminum frame box structure
ensures lightweight and strength, while the shape features a back-loaded transmission line design that delivers clean mid-bass
reproduction and natural cardioid behaviour. A Front Diffraction Waveguide (FDW) delivers wide horizontal dispersion, making
the system flexible and adaptable to many different applications.
The AX6C line array module has been designed to be used as a stand-alone or multiple column system in fixed installations,
frontfill, or under balcony applications, and for low-profile stage monitoring solutions. It can also be combined with AX12C and
AX12LF columns in multiple column systems in different configurations.
The AX6C can be driven by the SW2100A processed active subwoofer or by QC Series Class D processed amplifiers. Up to eight
AX6C modules (or different combinations of AX6C and AX12C) can be driven by one channel of the SW2100A subwoofer or of
a QC amplifier. Different presets for different combinations are available for the built-in CORE DSP, which can be also remotely
controlled using PRONET AX software.
Thanks to the elegant mechanical design the AX6C can be easily transported, while the integrated suspension system makes its
deployment very fast and simple. Each unit comes with two aluminum brackets and four pins that allows multiple array elements
to be easily combined either together, with the AX12C, or with the matching SW2100A subwoofer, or also in combination with
the complete range of mounting hardware available, including flybar and several brackets and stands.
TECHNICAL SPECIFICATION
SYSTEM
System's Acoustic Principle
Frequency Response (±3dB)
Nominal Impedance
Minimum Impedance
Horizontal Coverage Angle
Sensitivity (4V)
Maximum (peak) SPL
TRANSDUCERS
Type
Cone
Voice Coil Type
*measured @4 m and scaled @1 m
rev01_2018-03
USER MANUAL
AX6C
High Output Column Array
Line Array Element
Short Transmission
Line Back Loading
Front Diffraction Waveguide
200 Hz - 16 KHz (Processed)
32 Ohm
25 Ohm
100° (-6 dB)
102 dB SPL @ 1m*
124 dB SPL @ 1m*
6 x 3.5" (88mm) Neodymium
magnet woofers, 1" (25mm) VC
Waterproof Cone
Ventilated voice coil
• 6 x 3.5" neodymium transducers with waterproof cones
• Acoustic transmission line back loading design, resulting in clean mid-bass
reproduction and natural cardioid behaviour
• Wide horizontal dispersion through Front Diffraction Waveguide (FDW)
• Line Array dispersion characteristics
INPUT CONNECTIONS
Connector Type
POWER HANDLING
Continuous AES Pink Noise Power
Program Power
ENCLOSURE & CONSTRUCTION
Width
Height
Depth
Enclosure Material
Paint
Flying system
Net Weight
Neutrik® Speakon® NL4 x 2
(1+/1- signal IN & LINK ; 2+/2- thru)
180 W
360 W
107 mm (4.2")
626 mm (24.6") - without flying system
673 mm (26.5") - with flying system
193 mm (7.6")
Aluminum
High resistance, water based paint, black or
white finish
Aluminum Fast Link structure with dedicated pins
6.6 kg / 13.8 lbs. (without flying system)
8.7 kg / 19.1 lbs. (with flying system)
