Altronix MAXIMAL FIT MaxFit E Series Installation Manual page 8

MaxFit Enclosure Dimensions (approximate):
1.25" (31.8mm)
6.25" (158.8mm)
1.25" (31.8mm)
1.50"
(38.1mm)
0.569" (14.5mm)
1.50"
(38.1mm)
1.25" (31.8mm)
1.25" (31.8mm)
Altronix is not responsible for any typographical errors.
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty
IIMaxFit3E/5E/7E Series
- 8 -
20.5" x 16.5" x 6.25" (520.7mm x 419.1mm x 158.8mm)
7.00" (177.8mm)
0.75" (19.1mm)
7.00" (177.8mm)
7.00" (177.8mm)
16.50" (419.1mm)
1.25" (31.8mm)
1.00" (25.4mm)
7.00" (177.8mm)
B11V
MaxiFit3E/MaxFit5E/MaxFit7E Expandable Power Systems Installation Guide
1.25" (31.8mm)
1.25" (31.8mm)
1.25" (31.8mm)
1.50" (38.1mm)
1.50" (38.1mm)
1.25" (31.8mm)
1.25" (31.8mm)
1.25" (31.8mm)
MEMBER
