HOMCOM A90-194 Assembly Instruction Manual page 6

STEP 3
a. Before fixing the Handlebar Support Tube (11), please connect the tension and sensor cables as
shown in the following illustrations:
(1) Adjust the tension control to 8 levels, making sure the super tension cable (11-1) to bet the longest.
(2) Connect the supper tension cable (11-1) and (1-1) as shown in the figure, and connect the other
cable (1-2) and (11-2).
b. After finish connecting all cables, insert the Handlebar Support Tube (26) to the front opening tube of
the Main Frame (1), to tighten it with 4 X Ø8 Curved Washers (12) and 4 X M8*16 Hexagon Screws
(13) by L shape wrench (23).
