- Page 1 INada082V01_UK A90-198 User Manual READ AND SAVE THESE INSTRUCTIONS FOR FUTURE USE ASSEMBLY INSTRUCTION...
-
Page 2: General Instructions
PRE-ASSEMBLY INSTRUCTIONS GENERAL INSTRUCTIONS Carefully read through the instructions contained in this manual. It provides you with important information about assembly, safety and use of the machine. This unit has been designed for home use. The weight of the user must not exceed 275 lbs. - Page 3 8. This appliance must only be used for the purposes described in this manual. DO NOT use accessories that are not recommended by the manufacturer. 9. Do not place sharp objects near the machine. 10. Disabled people should not use the machine without the assistance of a qualified person or a doctor.
-
Page 4: Exploded View
EXPLODED VIEW... -
Page 5: Part List
PART LIST Part number Description Quantity Main frame Nuts washer bolts Front Stabilizer Rear Stabilizer pedal L/R Seat post Seat Knob Lower phone cover Handle bar supporter Limit screw Handlebar Combination screw Upper phone cover Cover screws Monitor holder Monitor Self-tapping screw Bottle holder Bottle holder screws... - Page 6 ASSEMBLY INSTRUCTIONS STEP 1 Fasten the front stabilizer (5) and rear stabilizer (6) on the frame (1) with 2 sets of bolt (4) ,washer (3) and cap nut (2).
- Page 7 STEP 2 Fasten the front Get the Seat post (8) and inserted into the frame (1) and tightened with a knob(10). and then put the seat (9) onto the seat post and screwed with a wrench(27). Remove the pedal (7) and screw the foot pedal L into the left crank of At last , the main frame (1), and the foot pedal R is screwed into the right crank.
- Page 8 STEP 3 First , get the handle bar supporter(12) together with lower phone cover(11) inseted into the frame and the knob to tighten , then use the (25) Allen wrench to lock the upper limit screw (13) . Second ,remove the handle (14) and secure the handle bar to the Handle bar with the combination screw (15) and the wrench (24).
- Page 9 STEP 4 Remove the monitor holder (18) and attach it to the handlebar (14). Then the monitor (19) is stuck on the monitor holder , use the screwdriver to tighten the self-tapping screw,and connect the cable . sensor At last , lock the bottle holder...
- Page 10 Step 5 STEP 5 If the spin bike is not stable when riding, please adjust the height of the Adjust mat (23).
- Page 11 COMPUTER OPERATING INSTRUCTIONS SCAN Scans all functions – TIME, SPEED, DISTANCE, TOTAL DIST, PULSE, CALORIES TIME Displays work out time lapse while exercising SPEED Displays the current speed DISTANCE Displays the distance while exercising TOTAL DIST Displays the total distance at the end of your workout PULSE Displays your heart rate CALORIES...
-
Page 12: Maintenance
MAINTENANCE Regular maintenance will prolong the life of your spin bike and prevent injury. We strongly recommend that you do the following on a regular basis: 1. Clean the bike after use with a soft cloth – ensure it is dry. Note, a build up of moisture over time will cause corrosion.
