Layer Parameters / Cut Parameters
Layer: Indicates current layer need to be altered. Click left layer bar to
switch to the layer need to be altered.
Work mode: Includes "cut","engrave","cut after engraving","hole", if
current layer is BMP (like )it only includes "engrave"(It can be only used in
engraving)。
Select "cut" or "cut after engraving" in【Work mode】, cut parameter is valid
as below image:
Cut Parameters
Speed: Working speed of laser head during cutting.
Working power: Maximum power; To adjust the maximum value of laser
power during processing
Corner power: Minimum power; the lowest power value during variable
motion. It's the power of (Make sure laser intensity constant during
process by adjusting above two parameters).
Overlap length: Due to tolerance with machine, probably it will happen
that closed image can't be layer(Unit:%). It's the power of laser 1 of
AWC708 control panel. Laser1 of AWC708 control panel. cut off. So this
parameter can help to solve this problem. But this parameter should not be
too large. Suggest adjusting precision of machine to solve this problem.
