Creating Basic Graphics & Editing Nodes
Create Basic Graphics
How to :
Draw a straight line: Click [line] option in [Draw] menu, or click. Drag the mouse on screen to draw any
line. Press "Ctrl" key and drag the mouse at the same time to draw horizontal line.
Draw a polyline: Click [Polyline] option in [Draw] menu, or click . Drag the mouse on screen to draw any
line.
Draw a Bezier: Click [Bezier] option in [Draw] menu, or click. Drag the mouse on screen to draw Bezier.
Draw a Rectangle: Click [Rectangle] option in [Draw] menu, or click.Drag the mouse on screen to draw
rectangle at any size. Press "Ctrl" key and drag the mouse at the same time to draw square.
Draw an Ellipse: Click [Ellipse] option in [Draw] menu, or click. Drag the mouse on screen to draw ellipse at
any size. Press "Ctrl" key and drag the mouse at the same time to draw circle.
Edit a text : Click [Text] option in [Draw] menu, or click. Double click on the left mouse button, and open
dialog box as shown:
Choose font, input or select font size, input text and then click [OK].
