9
Work Space
Nudge Offset: Determines the distance that laser head moves
when arrow buttons are pressed on control panel.
Paste Offset: Offset distance when copying the offset
distance of selected object.
Language: Determines language used.
Speed Unit: Determines the units of measure used in
machine.
Machine Zero: Determines default origin of machine
(Zero/Limit position). The setting must be exactly the same
with the actual machine zero position, or the machined image
could be reversed or flipped.
Selected Color: Determines color of selected object.
Show Grid: Toggle on or off to show grid on drawing area.
Grid Distance: Adjusts the distance of the grid lines.
Simulating show objects of engraving: System will simulate
and show the engraving image. However, if the data volume
of engraving image is too large, the system will render slowly
when showing the view.
