LaserCAD QuickStart

1. Open LaserCAD
2. Open, draw, or import selected image onto LaserCAD that is going to be cut or engraved.
3. Connect the USB-C from the computer to the laser machine.
4. For the first time, to add and recognize the laser machine, press the "Select mode" button on the right side. Then
click the "add" button for USB connection and then "Find Com."
5. Once this is done, press
6. Enter the user parameters tab or manufacturer's parameters and click "READ."
7. Once this is done the parameters should be set accordingly to the machine.
8. Double click on the layer on the right and it will bring up the Layer Parameters.
9. In this page, the power and speed of the laser can be adjusted. The option to cut or engrave is available on this
page.
10. After everything is set on the computer remember to "SAVE". Then, click on the Download button on the right side of
LaserCAD > Download Document. This will send the project to the laser machine with the newly added settings.
11. After this is done, press "Reset" on the DSP controller to apply the new changes.
12. If everything on the display looks correct, try pressing "box" on the DSP controller to make sure that the dimensions
of the image to be cut or engraved are correct.
13. If everything is set properly, press start to begin cutting or engraving the image.
located near the top of the screen to enter system options.
