Open & Save Files
The files used by the software is PWJ format. The pwj5 file saves the image information, all layer parameters, and all image
elements processing sequence. By saving all imported image data as pwj5 format, it will make it easier for the image processing.
Import & Export Files:
As the file format used in this software is PWJ5, importing is required when you need to make or edit image. There are different
formats for importing and exporting images so that it can apply to the software. Supported importing formats are DXF, AI, PLT, DST,
DSB and so on; Supported exporting format is: PLT.
Import file
Click [Import] option or (Ctrl+I) in [File] menu and open dialog box as below, Select corresponding file and click [Open]
[Unite Lines]: Apply unite lines setting when importing the image. (Introduction of [Unite Lines], please refer to 3.13.5)
[DST,PLT Auto Smooth]: Apply auto smooth setting when importing the image. (Introduction of [Auto Smooth] please refer
to 3.13.3)
[Auto Order]: Apply auto order setting when importing the image. (Introduction of [Auto Order], please refer to 3.13.2)
[PLT Unit]: Indicate the dimension of one unit in PLT file, different values make different importing image dimensions.
[Reserve the current document]: Upload data of imported file while keeping the original image data. So after importing, the
image includes both the original data and the imported file data.
[Preview]: Preview the file image when selecting the file.
Export File
Click [Export] option or (Ctrl+E) in [File] menu, and open dialog box as below, Input file name and click [Save].
17
