Click Options, then array output options.
Cell width(X): Original size of datum
Cell height(Y): Original size of datum
Count: Rows and columns of datum to be output.
Offset: distance between every row or every
column.
Width: Width of all datum after array.
Height: Height of all datum after array.
Auto convert calculation: According to the space,
calculate the rows and columns needed
automatically. Click Auto convert calculation

Array Output Options

Material width(X): Width of
material to be dealt with(default
as width of workbench)
Material height(Y): Height of
material to be dealt with(default
as width of workbench)
System will calculate the number
of material to be dealt with
according to material size.
23
