certain circumstances. No solid obstructions are allowed above
the unit at any height, see Case 5 on
temperature operation is expected, optional louvers should be
installed if the unit has no protection against prevailing winds.
Figure 4: Spacing Guidelines for Sufficient Airflow
Minimum³ = 4 feet (1.2 m)
(Must have 8 ft. on one
side for coil removal)
Minimum 8 feet (2.4 m) service
clearance on this end
Minimum may be reduced to
4 ft (1.2 m) if evaporator can be
removed from the side.
Minimum³ = 4 feet (1.2 m)
NOTE: 1. There should be no obstruction above the fan deck
to interfere with fan discharge.
2. Electrical conduit and field installed electrical
devices should not block service access to any chiller
components.
3. Integrated Waterside Economizer (IWSE) units
need a minimum side clearance of 5 ft (1.5 m) as
measured from the outer base rail of the unit.
4. For installations of 2 or more units, refer to Case 2
and Case
3.
5. Stated spacing guidelines are for achieving
sufficient airflow without incurring performance
losses. See Cases 1 to 5 for capacity reduction and
power increases when sufficient airflow cannot be
achieved.
6. Ensure all local and national building code
requirements are met.
www.DaikinApplied.com
page 14.
If low ambient
No obstructions.
Recommended area
is applicable for
service access ONLY.
Performance
clearance graphs are
provided in submittal
documents and may
require additional
spacing.
Minimum⁶ = 4 feet
(1.2 m)
Lorem ipsum
9
Installation and Application Considerations
Case 1: Building or Wall on One Side of Unit
For most models, maintain a 4 foot minimum from a wall of any
height; however, performance may be affected at this distance
due to air recirculation and elevated condenser pressure.
Assuming all service clearance requirements are met,
6
to
Figure 10
depict Case 1 performance adjustments as
the wall height and distance increases. For AWV models with
IWSE option, the minimum distance from a wall of any height
is 5 feet as measured from the outer base rail of the unit and
performance adjustments are represented in
Figure 14.
Figure 5: Building or Wall on One Side of Unit
Height
of
Wall
Distance
Between
Wall
and
Unit
Figure 6: Case 1 for AWV 008-010 Models
% Full Load Capacity Reduction (AWV008-010)
1.2%
1.0%
0.8%
0.6%
0.4%
0.2%
0.0%
8
12
% Full Load Power Increase (AWV008-010)
2.5%
2.0%
1.5%
1.0%
0.5%
0.0%
8
12
IOM 1242-8 • PATHFINDER
Figure
Figure 11 to
Control Panel
16
20
Height of Wall - Feet
16
20
Height of Wall - Feet
MODEL AWV CHILLERS
®
4 Feet
5 Feet
6 Feet
24
4 Feet
5 Feet
6 Feet
24
