Case 2: Two Units Side-by-Side
For most models, there must be a minimum of 6 feet between
two units placed side-by-side; however, performance may
be affected at this distance due to air recirculation and
elevated condenser pressure. Assuming all service clearance
requirements are met, Figure 15
2 performance adjustments as the distance between two
units increases. For AWV models with IWSE option, the
minimum distance between two units side-by-side is 8 feet as
measured from the outer base rail of the unit and performance
adjustments are represented in
Figure 15: Case 2 - Full Load Capacity Reduction
Full Load Capacity Reduction
6.0
5.0
4.0
3.0
2.0
1.0
0.0
6 8
Distance Between Units (ft)
AWV008
AWV016
AWV024
Figure 16: Case 2 - Power Increase
Full Load Power Increase
7.0
6.0
5.0
4.0
3.0
2.0
1.0
6 8
Distance Between Units (ft)
AWV008
AWV016
AWV024
IOM 1242-8 • PATHFINDER
and Figure 16 depict Case
Figure 18 and Figure 19.
10
AWV010 AWV012 AWV014
AWV018 AWV020 AWV022
AWV026 AWV028 AWV030
10
AWV010 AWV012 AWV014
AWV018 AWV020 AWV022
AWV026 AWV028 AWV030
MODEL AWV CHILLERS
®
Installation and Application Considerations
Figure 17: Two Units, Side-by-Side
Figure 18: Case 2 - Full Load Capacity Reduction - IWSE
Option
Full Load Capacity Reduction
5.5
5.0
4.5
4.0
3.5
3.0
2.5
2.0
1.5
12
1.0
8
AWV012
AWV020
AWV028
Figure 19: Case 2 - Power Increase - IWSE Option
Full Load Power Increase
6.5
6.0
5.5
5.0
4.5
4.0
3.5
3.0
2.5
12
2.0
8
AWV012
AWV020
AWV028
12
D
10 12
Distance Between Units (ft)
AWV014 AWV016
AWV022 AWV024
AWV030
10 12
Distance Between Units (ft)
AWV014 AWV016
AWV022 AWV024
AWV030
