SC2000E(Mini) Series Vision Sensor Quick Start Guide

1.1 Introduction

With built-in positioning and measurement algorithms, SC2000E(Mini) vision sensor can detect
object's existence, count patterns and spot, etc. It can be monitored and operated via the SCMVS
client. It can output results via RS-232 and Ethernet, and cooperate with other processes via IO. The
vision sensor supports multiple result output methods and customized result text output.

1.2 Key Feature

● Adopts embedded hardware platform for high-speed image processing.
● Adopts built-in positioning and measurement algorithms to detect object's existence, count
patterns and spots, etc.
● Multiple IO interfaces for input and output signals.
● Multiple indicators for displaying device status.
● Adopts light source to ensure uniform brightness in the illuminated area.
● Supports multiple communication protocols, including Serial Port, TCP, UDP, FTP, Profinet,
Modbus, Ethernet/IP, etc.
Note
● The device's functions may differ by models.
● Refer to the user manual of the SCMVS client software for detailed device operations.
