4.1 Installation Preparation

You need to prepare following accessories before installation.
No. Name
1 17-Pin Cable
2 Network Cable
Power Adapter or Switch
3
Power Supply
4 Screw Package

4.2 Install Device

Before You Start
● Make sure that the device in the package is in good condition and all assembly parts are included.
● Make sure that all related devices are powered off during the installation.
Steps
1. Use M2 screws to fix the device to the installation position.
2. Use the supplied 17-pin cable to wire the device to a suitable power adapter or switch power
supply.
3. Use the network cable to connect the device via the 17-pin cable's RJ45 connector to a switch or
a network interface card.
SC2000E(Mini) Series Vision Sensor Quick Start Guide

Chapter 4 Installation

Table 4-1 Accessories
Quantity
1
1
1
1
It refers to the supplied 17-pin cable that is included
in the package.
It refers to category 5 network cable or above. You
need to purchase separately.
You should select suitable power adapter or switch
power supply according to the device power supply
and consumption. You need to purchase separately.
It refers to the supplied M2 screws that are used to fix
the device to the installation position.
6
Description
