7.1.2 Configure as Output Signal

If the bi-directional I/O is configured as output signal, its output signal polarity is NPN, and its logic
level and electrical feature are shown below.
50%
Internal
Logic
Output
Level High
Output
Level Low
When the external voltage is 12 VDC and pull-up resistor is 1 KΩ, output electric feature is shown
below.
50%
TDF
50%
Figure 7-2 Input Logic Level
Table 7-1 Input Electrical Feature
Parameter Symbol
VL
VH
TDF
TDR
TDF
90%
50%
10%
TF
Figure 7-3 Output Logic Level
15
50%
TDF
50%
Value
1 VDC
2 VDC
200 ns
1 μs
50%
TDR
90%
TR
50%
10%
