SC2000E(Mini) Series Vision Sensor Quick Start Guide
No. Name
6 STS Indicator
PWR Indicator
7
8 Light Source
9 Sensor
10 Aiming Light
It is a status indicator. The indicator is green when the solution loads
normally. When the device starts or loading the solution fails, it is red.
It is a power indicator. The indicator is green when the device operates
normally. When the device starts or exception occurs, it is red.
It is the LED light source used to provide light when the device acquires
images.
It is used to acquire images.
It helps to indicate the field of view and aim targets.
Description
3
