Compressor Name Plates - Johnson Controls SABROE ComPAC Operating Manual

Safety
2.2.3

Compressor name plates

No
Compressor Type
Refrigerant
Swept volume
Pressure system
Allowable pressure Max.
Test pressure
Fig. 5: Name plate for standard compressor
Fig. 7: Name plate for compressor with EurAsian Con-
formity mark (EAC)
Operating manual - ComPAC
011769 en 2020.03
2516-345
Year
Speed rpm
m 3 /h
HP side
LP side
bar g
bar g
15/56
No
Compressor Type
Refrigerant
Swept volume
Pressure system
LP side
Allowable pressure Max.
Test pressure
Fig. 6: Name plate for ATEX compressor
Johnson Controls Denmark ApS
Christian X's Vej 201
8270 Højbjerg, Denmark
www.sabroe.com
No
Compressor Type
Refrigerant
Swept Volume
LP side
Pressure system
Allowable pressure Max.
Test pressure
Fig. 8: Name plate for compressor to the USA
Year
Speed rpm
m /h
3
HP side
bar g
bar g
2516-347
Year
Speed rpm
cfm
HP side
psig
psig
