Signs

All signs which may be found on your equipment are shown below. The number of signs, however,
may vary from one product to another.
Risk of electric shock
Internal overpressure
Do not step on surface
Internal protection
Compressor blocks and units are usu-
ally delivered without refrigerant and
oil. To protect the compressors against
internal corrosion, they are delivered
evacuated of all atmospheric air and
charged with dry Nitrogen (N
overpressure of 0.5 bar [7.3 PSI].
In such cases, a yellow sign is affixed
to a visible spot on the compressor.
High voltage/
High pressure
Hazardous substance
No open flame
Pacemaker users keep out
The magnetic field on the rotor may
affect pacemakers. The motor rotor
contains a powerful magnetic field.
This field may affect digital devices
such as watches and mobile phones.
) to an
Assembly or maintenance of the rotor
2
must not be carried out by people with
pacemakers or any other implanted
medical electronic device.
18/56
High surface
The compressor may be
temperature
(about 70°C)
Dangerous noise level,
Cold surfaces
use hearing protectors
The unit IS filled with re-
Flammable gas
The VSD contains capacitors capable
of storing electrical energy, meaning
that there is a risk of electric shock
within 15 minutes after the drive has
been turned off.
