Design and function

3. Design and function
3.1

Unit design

3.1.1

The ComPAC unit in general

The ComPAC is a complete, factory-manufactured chiller unit intended for water or brine cooling.
The ComPAC is equipped with a water-cooled condenser.
The ComPAC only uses R717 as refrigerant. Once the unit is charged with R717, connected to
electricity, and pipe connections to water/brine are established, it is ready for operation.
The unit is provided with adjustable anti-vibration machine feet for installation on a solid concrete
floor. For installation on decks, special vibration dampers are often required.
The ComPAC units are controlled by Johnson Controls Denmark's Unisab III control and capacity
regulating system.
For specific dimensions and size of connections, see P&I diagram and GA drawing.
