WATER-COOLED SELF-CONTAINED UNITS
Supersedes 145.05-NOM7 (818)
Form 145.05-NOM7 (1019)
INSTALLATION, OPERATION AND MAINTENANCE
035-22910-007
MODEL LSWU/LSWD/LSWF
WITH IPU2 CONTROL
25–105 TON
Issue Date:
October 31, 2019
