The unit name plate is positioned on the frame and contains this information:
Refrigeration unit No.
Year
Type
Scope
Design code
Approval no.
Refrigerant - Fluid
Refrigerant - Group
Supply voltage - Control
Refrigerant charge
Pressure system
Category
Allowable pressure, max.
Test pressure
Allowable temperature,
min./max.
CE xxxx
Ex
EAC
Note: Main supply voltage can be found on the motor and/or electrical panel name plate.
Identification no. (serial no.)
Year of manufacturing.
Manufacturer's type designation.
For EC PED/EAC approval: 'Unit & Piping' means that the CE/EAC
mark applies to the complete unit including the piping system.
'Piping' means that the CE/EAC mark applies to the piping system
only, and it is the sole responsibility of the owner to ensure and
declare that the complete unit is in conformity with the provisions
of all relevant rules.
Design code used for the unit and piping system.
If the unit/manufacture has been approved by a 3rd party/notified
body.
Refrigerant of the unit.
Refrigerant designation according to ISO 817.
For EC PED approval:
Fluid group 1 or 2 according to the PED directive.
Supply voltage and frequency of the control system.
Weight of the refrigerant charge on the unit.
This is only stated if the unit includes an evaporator and/or a
condenser.
The low-pressure side of the unit piping system is referred to as
the LP side.
The high-pressure side of the unit piping system is referred to as
the HP side.
For EC PED approval:
The maximum category of the piping system (CAT 1, 2 or 3) or of
the assembly unit and piping (CAT 3 or 4).
The max. pressure (pressure relative to atmospheric pressure)
that the unit/piping system has been designed for in terms of
pressure strength design.
The maximum practical operation pressure is lower than the maxi-
mum allowable pressure depending on the operating conditions
and safety equipment settings.
The test pressure that the unit/piping system has been strength
tested with.
The minimum and maximum temperatures that the unit/piping
system has been designed for at the indicated maximum allowable
pressures.
The CE mark appears on the name plate for EC PED approval only.
The four digits make up the registration no. of the notified body/
3rd party in charge.
If the unit is designed in accordance with the EC ATEX directive,
there is an Ex mark on the name plate.
The EurAsian Conformity mark (EAC) indicates that the unit is in
compliance with all relevant technical regulations of the Eurasian
Customs Union.
