SVIM-1
LE
To limit the unit's exposure to noxious gases install it
in a hallway.
Make sure the unit is properly installed, that is, side
up with the cable entry holes facing down.
The SVIM-1 will operate in a temperature range of
LE
32°F to 120°F (0°C to 50°C).
The enclosure is watertight, it is not splash-proof or
immersion-proof.
WATER on the control. Cover it carefully with plastic
before cleaning the room. Also, DO NOT drill
additional holes in the enclosure.
Install in an area protected from sunlight.
It is prohibited to use overhead cables outside the
building.

2.2 INSTALLATION

•
Use a screwdriver to remove the faceplate and the
power compartment's cover.
•
Once both faceplates are off, install the mounting
screw on the wall and install the unit on it.
•
Secure the SVIM-1
mounting holes.
Mounting hardware is not included with the unit.
Page 8
www.monitrol.com
DO NOT USE PRESSURIZED
in place using the bottom
LE
