3.2 PARAMETERS

The current section gives a description of the SVIM-1
parameters and how to operate them.
3.2.1 ACTUAL POS Refer to figure 5 (5)
The Actual Position parameter makes it possible for
users to know the exact curtain position (CLO, 1, 2...,
99, OPEN). When the SVIM-1
the message CAL is displayed.
3.2.2 MAN / AUTO Refer to figure 5 (6)
The Manual / Automatic parameter enables users to
switch the SVIM-1
The following examples
button in various modes.
1- In auto mode, press once on MAN/AUTO. The LED
window displays a blinking "AUTO". Press the same
button once more to switch to manual mode and a
flashing "Desired Position" will be displayed. The
position can now be changed by pressing the
adjustment buttons(
2- In manual mode, press on MAN/AUTO once. The
desired position displayed is blinking. Press the same
button once more to switch back to auto mode.
3- During calibration cycles, the position can not be
manually changed. The message "CAL" is displayed
and the MAN/AUTO button is locked.
3.2.3 SETUP Refer to figure 5 (7)
The setup button allows modification of configuration
parameters. They can be accessed one after the other
by pressing the SETUP button.
The following sub-parameters
pressing consecutively the SETUP button.
Page 22
www.monitrol.com
is in a calibration cycle,
LE
from automatic to manual mode.
LE
show the functions of this
).
are accessed
LE
by
