8
exit delay is running – less than 10 seconds remained
armed – mode: "full"
armed – mode: "day"
armed – mode: "night"
entry delay is running
fire alarm
alarm
warning alarm
tamper alarm
fire alarm memory
alarm memory
warning alarm memory
tamper alarm memory
8.3

Zone state

The widget displays the zone state represented by either:
• icons selected by SATEL (indicator) – different states are displayed,
• text messages (text) – messages inform only about normal and violated states,
• icons selected by the installer (icon) – only normal and violated states are displayed.
The icons selected by SATEL are described in the table below.
Icon
normal
violated
trouble – long violation
trouble – no violation
inhibited
isolated
