- Page 1 Keypad INT-TSG2R Firmware version 2.01 USER MANUAL – PERFECTA 64 M int-tsg2r_op_en 03/24 SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND tel. +48 58 320 94 00 www.satel.pl...
- Page 2 This is a Class A product. In a domestic environment this product may cause radio frequency interference. Hereby, SATEL sp. z o.o. declares that the radio equipment type INT-TSG2R is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.satel.pl/ce...
-
Page 3: Table Of Contents
CONTENTS 1. Introduction ........................3 2. LED indicators ........................3 3. Using the touch screen ...................... 3 4. Screensaver ........................5 Slideshow ........................6 Trigger the panic alarm ....................6 5. User screens ........................6 6. Additional screens ......................8 7. - Page 4 INT-TSG2R SATEL 10.8.2 Using the terminal ................... 21 10.9 “Keypad” screen......................25 10.9.1 Setting the screen brightness ................25 10.9.2 Setting the keypad volume ................26 10.9.3 Setting the auto logout time ................26...
-
Page 5: Introduction
In order to control the alarm system, you can use: • user screens and additional screens created for you by the installer, • user menu created by SATEL. Use the gestures described below. - Page 6 INT-TSG2R SATEL Tap on an item on the screen. Tap and hold Tap on an item on the screen and hold for 3 seconds. Swipe up / down Tap the screen and slide your finger up or down to: • swipe the screen up / down (move between the screensaver / user screen / user menu home screen), •...
-
Page 7: Screensaver
SATEL INT-TSG2R Swipe right / left Tap the screen and slide your finger right or left to swipe the screen right / left (go to the previous / next screen). When the screensaver is active, swipe right / left to start / end the slideshow. -
Page 8: Slideshow
INT-TSG2R SATEL Fig. 1. Screensaver (keypad with factory default settings). The screensaver on a keypad with factory default settings (Fig. 1) shows the date and time. The installer can add to the screen additional widgets that will indicate the alarm system status (see “Widgets”... - Page 9 SATEL INT-TSG2R The user screen includes: • status bar (see p. 8), • widgets used to operate the alarm system, indicate the alarm system status, etc. (see “Widgets” p. 8). Fig. 2. User home screen (keypad with factory default settings).
-
Page 10: Additional Screens
For this reason, the additional screens may be used to display site plans. If pictures other than the ones offered by SATEL are to be displayed, the installer must save them on a memory card and install the card in the keypad. -
Page 11: Partition State
Zone state The widget displays the zone state represented by either: • icons selected by SATEL (indicator) – different states are displayed, • text messages (text) – messages inform only about normal and violated states, • icons selected by the installer (icon) – only normal and violated states are displayed. -
Page 12: Output State
The widget displays the output state represented by either: • icons selected by SATEL (indicator), • text messages (text), • icons selected by the installer (icon). The icons selected by SATEL are described in the table below. Icon Output status deactivated activated “15: Controlled”... -
Page 13: Rectangle
SATEL INT-TSG2R Rectangle The widget displays a rectangle that can be translucent and have different colors. As an additional graphic element it may be used e.g. to highlight a part of the screen. Macro The icon for the widget is selected by the installer. Tap the widget to run a macro command. -
Page 14: On-Screen Keypad
INT-TSG2R SATEL Tap the widget to change the temperature settings for the thermostat. The thermostat settings are used to adjust the operating parameters of the ART-200 wireless radiator thermostats. 9. On-screen keypad The on-screen keypad is displayed when you are required to enter a code e.g. to access the user menu. -
Page 15: User Menu Home Screen
SATEL INT-TSG2R 10.1 User menu home screen Fig. 5. User menu home screen. The following functions are available on the user menu home screen. tap to go to the “Partitions” screen (p. 14). tap to go to the “Zones” screen (p. 16). -
Page 16: Partitions" Screen
INT-TSG2R SATEL Fig. 6. QWERTY keyboard: letter keys mode. In addition to the typing keys, the following special keys are available. tap to switch the keyboard to the uppercase mode. tap to switch the keyboard to the lowercase mode. tap to exit the QWERTY keyboard. -
Page 17: Arming
SATEL INT-TSG2R Fig. 8. “Partitions” screen (example). The icons in the top right corner allow you to: tap to clear alarm. tap to terminate the exit delay. tap to filter the partition list (see “Filtering the partition list” p. 16). -
Page 18: Disarming
INT-TSG2R SATEL 4. Tap the button with the arming mode you want to activate. 5. Tap the button with the icon. The arming procedure will start. 10.3.2 Disarming 1. Tap the partition you want to disarm. The button with the icon will appear at the bottom of the screen. -
Page 19: Zone Inhibiting
SATEL INT-TSG2R tap to search for zone/zones (see “Searching for zones” p. 18). tap to go back to the user menu home screen. The icon displayed in front of the partition name allows you to: tap to hide the list of zones that belong to the partition. -
Page 20: Zone Unbypassing
INT-TSG2R SATEL 10.4.3 Zone unbypassing 1. Tap the zone you want to unbypass. The button with the icon will appear at the bottom of the screen. 2. If you want unbypass several zones, tap each zone one by one. 3. Tap the button with the icon. -
Page 21: Output Control
SATEL INT-TSG2R Information about how many outputs are activated is shown in brackets above the list of outputs ([number of activated outputs]/[number of outputs]). If you tap the screen close to the bottom edge and swipe up, the buttons with the icons will appear at the bottom of the screen: tap to increase the size of the icons/names on the list. -
Page 22: Keys
INT-TSG2R SATEL Fig. 11. Terminal. 10.8.1 Keys Functions of keys enter digits (code, partition number, etc.) view the troubles (tap and hold for 3 seconds) turn on/off the keypad CHIME (tap and hold for 3 seconds) trigger the medical alarm (tap and hold for 3 seconds) ) –... -
Page 23: Using The Terminal
SATEL INT-TSG2R Functions of keys arm the system in the day mode – see “Arming” terminate the exit delay (tap and hold for 3 seconds) disarm the system and clear the alarm – see “Disarming and alarm clearing” Availability of the functions depends on the keypad settings. - Page 24 INT-TSG2R SATEL 2. Select the arming mode (tap one of the keys: - full arming; - day arming; - night arming). 3. In the partition/partitions, the arming procedure will begin. Arming without delay If there is nobody in the partition or nobody is leaving the partition which is to be set to the day / night armed mode, you can arm the partition without exit delay.
- Page 25 SATEL INT-TSG2R User menu Enter the code and tap to get access to the user menu. The functions you can run will be displayed. The list of available functions depends on your rights, as well as on the state and configuration of the system.
- Page 26 INT-TSG2R SATEL function to enter the submenu / run the function. You can enter at once a sequence of several digits (corresponding to successive numbers of submenus and functions) to quickly run the selected function. For example, to start the zone inhibiting function, enter the user menu and then tap Remember that the sequence of digits which starts a function e.g.
-
Page 27: Keypad" Screen
SATEL INT-TSG2R 10.9 “Keypad” screen Fig. 12. “Keypad” screen. The functions available on the “Keypad” screen are described below. tap to set the screen brightness (see “Setting the screen brightness” p. 25). tap to set the keypad volume (see “Setting the keypad volume” p. 26). -
Page 28: Setting The Keypad Volume
INT-TSG2R SATEL screen brightness in the nighttime when the keypad is not used. beginning of the nighttime. screen timeout in the nighttime (if you set 0, the screen will not be turned off). Tap the button with the icon to confirm changes. Tap the button with the icon to cancel changes.
