7-2 Examples of Wiring for Each Application
7-2-8
Relay Outputs with Dual Channel Mode and EDM Input
An example of the wiring and configuration when using the DST1-MRD08SL-1 is shown
below.
Wiring
V0
G0
E1
KM1
GND
KM2
Configuration
Parameter
Group
Safety Input 0
0015
0016
0029
Test Output 0
0001
Safety Output 0
0006
0010
Safety Output 1
0007
7-10
IN0
V1
T0
G1
E2
GND
E1, E2: 24-V DC Power Supply (S8
KM1, KM2: Magnetic Contactors
M: 3-phase motor
F1, F2: Fuses
Parameter Name
Safety Input 0 Channel Mode
Safety Input 0 Test Source
Dual Channel Safety Input 0/1 Mode
Test Output 0 Mode
Safety Output 0 Channel Mode
Dual Channel Safety Output 0/1 Mode
Safety Output 1 Channel Mode
OUT
OUT
0
1
C0
C1
F1
F2
KM1
KM2
)
KM1
KM2
M
Value
Test pulse from test output
Test Output 0
Single Channel
Pulse Test Output
Used
Dual Channel
Used
