Appendix 1: DeviceNet Explicit Messages
Setting and Monitoring the Test Output Point
Explicit Read/
message write
Terminal Read Reads the monitor
Maintenance mode for
Information maintenance
Monitor Mode information of the
Read output (1 to 4)
specified by the
instance ID.
Write Writes the monitor
mode for
maintenance
information of the
output (1 to 4)
specified by the
instance ID
Output Set Read Reads the set value
Value for Total for the total ON time
On Time or (unit: s) or number
Contact of contact
Operation operations (unit:
operations) of the
output (1 to 4)
specified by the
instance ID.
Write Writes the set value
for the total ON time
(unit: s) or number
of contact
operations (unit:
operations) of the
output (1 to 4)
specified by the
instance ID.
Output Total Read Reads the set value
ON Time or for the total ON time
Contact (unit: s) or number
Operation of contact
Counter Read operations (unit:
operations) of the
output (1 to 4)
specified by the
instance ID.
Output Total Reset Resets the total ON
ON Time or time or number of
Contact contact operations
Operation for time output (1 to
Counter Reset 4) specified by the
instance ID.
Output Monitor Read Reads the set value
Status for Total for the total ON time
ON Time or or number of
Contact contact operations
Operation (unit: operations) of
Counter Read the output (1 to 4)
specified by the
instance ID.
A-8
Function
Service Class
Code
0E hex
10 hex
0E hex
09
10 hex
hex
0E hex
05 hex
0E hex
Command
Instance Attribute
ID ID ID
09 01 to 04
65 hex
hex hex
09 01 to 04
65 hex
hex hex
09 01 to 04
68 hex
hex hex
01 to 04
68 hex
hex
09 01 to 04
66 hex
hex hex
09 01 to 04
66 hex
hex hex
09 01 to 04
67 hex
hex hex
Response
Data size
1 byte
00 hex: Total ON
time mode
−
01 hex: Contact
operation counter
mode
1 byte
00 hex: Total
ON time mode
01 hex: Contact
operation
counter mode
4 bytes
0000 0000 to
−
FFFF FFFF hex
(0 to
4,294,967,295)
4 bytes
0000 0000 to
FFFF FFFF hex
(0 to
4,294,967,295)
4 bytes
0000 0000 to
−
FFFF FFFF hex
(0 to
4,294,967,295)
1 byte
00 hex: Within
range
−
01 hex: Over
range (over the
monitor value)
−
−
