PART IDENTIFICATION CHART

Use the drawings below to identify small parts used for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity used for assembly. Note: If a part is not in the hardware kit, check to see whether
it is preattached. Extra parts may be included.
M8 Nut
M8 x 19mm
Screw (8)–4
M10 x 45mm Screw (2)–4
M10 Nut
(12)–4
(11)–6
M4.2 x 13mm
Screw (5)–6
M8 x 38mm Bolt (7)–4
M10 x 75mm Screw (1)–4
M10 Star
Washer (13)–4
M4.2 x 19mm
#10 x 3/4"
Screw (3)–14
Screw (89)–2
M8 x 41mm Screw (9)–4
M10 x 70mm Bolt (6)–6
7
M10 Black Star
Washer (14)–4
