Electrical connection of the DL7 system:
The systems is to be connected as shown on figure 7. Each DL7/DL7R is to be connected to the sockets on the control box by
means of the motor cables, which have an 6-pin plug in each end.
Finally the mains cable is to be mounted and power switched on. Please note that the control box must only be
connected to the voltage stated on the label.
Hook for cable relief
Control/
DL
dongle
Mains cable
DL7
Figure 7
Page 14 of 24
or
DL7R
