Summary of Contents for DAPAudio PSS-106
- Page 1 USER MANUAL ENGLISH PSS-106 Battery Speaker Product code: D2612/D2613 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Charging the Battery ............................15 Installation of the Batteries (Wireless Microphone) ..................16 Setup ................................... 17 Safety Instructions for Operation ........................17 Switching the PSS-106 On/Off ........................17 Switching the Microphone On/Off .......................17 Muting the Microphone ..........................17 Connecting the Microphone to the Receiver....................17 Pairing Mobile Devices with the Receiver via Bluetooth ................18 Setup Examples ..............................18... - Page 3 PSS-106 Battery Speaker MP3 Mode ............................23 Bluetooth Mode ..........................24 Troubleshooting ..............................24 Maintenance ..............................25 Preventive Maintenance ..........................25 Basic Cleaning Instructions ........................25 Corrective Maintenance ..........................25 Deinstallation, Transportation and Storage ....................25 Instructions for Transportation ........................25 Storage ................................26 10. Disposal ................................26 11.
- Page 4 PSS-106 Battery Speaker Preface Thank you for purchasing this DAP product. The purpose of this user manual is to provide instructions for the correct and safe use of this product. Keep the user manual for future reference as it is an integral part of the product. The user manual shall be stored at an easily accessible location.
-
Page 5: Introduction
After unpacking, check the contents of the box. If any parts are missing or damaged, contact your Highlite International dealer. Your shipment includes: ● DAP PSS-106 Battery Speaker ● Antenna (only in D2613) ● Wireless microphone (only in D2613) ●... -
Page 6: Symbols And Signal Words
PSS-106 Battery Speaker Symbols and Signal Words Safety notes and warnings are indicated throughout the user manual by safety signs. Always follow the instructions provided in this user manual. Indicates an imminently hazardous situation which, if not avoided, will result in DANGER death or serious injury. -
Page 7: Safety
PSS-106 Battery Speaker Safety Important Read and follow the instructions in this user manual before installing, operating or servicing this product. The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual. Warnings and Safety Instructions... - Page 8 PSS-106 Battery Speaker ● Do not bypass the thermostatic switch or fuses. ● Do not let the power cable come into contact with other cables. Handle the power cable and all connections with the mains with caution. ● Do not modify, bend, mechanically strain, put pressure on, pull or heat up the power cable.
-
Page 9: Requirements For The User
PSS-106 Battery Speaker Attention Before each use, examine the device visually for any defects. Make sure that: ● There are no deformations on the housing. ● The power cables are not damaged and do not show any material fatigue. Attention Do not expose the device to conditions that exceed the rated IP class conditions. -
Page 10: Description Of The Device
PSS-106 Battery Speaker Description of the Device The DAP PSS-106 is a battery-powered wireless loudspeaker. It can be used as floor monitor, a tilt back or as a PA. The advanced version (D2613) includes the wireless microphone and the wireless microphone receiver with an antenna. -
Page 11: 3-Channel Mixer
PSS-106 Battery Speaker 3-channel Mixer Fig. 03 Combo 3-pin XLR/6,3 mm jack IN (balanced/unbalanced) Microphone/Line impedance switch CH1 Bass control CH1/CH2 Treble control CH1/CH2 Input gain control CH1/CH2 Reverb control Master volume control Voice priority switch ON/OFF Signal/Clip LED indicator (Green/Red) -
Page 12: Wireless Microphone Receiver
PSS-106 Battery Speaker Wireless Microphone Receiver Fig. 04 LCD display UP button Microphone signal volume control SET button DOWN button Media Player Fig. 05 USB A connector IN LCD display MODE button FORWARD/VOLUME + button PLAY/PAUSE button BACKWARD/VOLUME – button... -
Page 13: Product Specifications
PSS-106 Battery Speaker Product Specifications Model: DAP PSS-106 Battery Speaker with Wireless Handheld Mic Physical: Dimensions (speaker): 265 x 240 x 325 mm (L x W x H) Weight (speaker): 5,9 kg Dimensions (microphone): 240 x 50 x 50 mm (L x W x H) -
Page 14: Optional Accessories
You can additionally purchase the following accessories: Product code: D2614 (Transport Cover for PSS-106) Product code: D2621 (DAP WM-10 Handheld Microphone for PSS-106) Product code: D2622 (DAP BP-10 Beltpack for PSS-106) Product code: D2625 (DAP WR-10 Wireless Receiver for PSS-106) -
Page 15: Installation Site Requirements
PSS-106 Battery Speaker Installation Site Requirements ● This device can be used only indoors. ● The device must be installed away from heating sources and direct sunlight. ● The maximum ambient temperature t = 40 °C must never be exceeded. -
Page 16: Charging The Battery
PSS-106 Battery Speaker Option 3: installation as a floor monitor The device functions only as a floor monitor. This way, the artist is able to hear his own output during performance. There is a HPF (high-pass filter) button at the side of the device that gets pressed when you install the device in this position. -
Page 17: Installation Of The Batteries (Wireless Microphone)
PSS-106 Battery Speaker Installation of the Batteries (Wireless Microphone) The wireless microphone is delivered without batteries. It accepts 2 x AA LR6 (alkaline) batteries. Rechargeable Ni-Cad batteries can be used but they do not supply adequate current for more than 4 hours. -
Page 18: Setup
Before use, pair the microphone and the receiver. You need to do this for the system to work properly. To pair the microphone with the receiver: Switch the PSS-106 and the microphone on. Press the UP/DOWN buttons (30/33) to choose one of the 9 channels (0–8). Alternatively, press and hold down the DOWN button (33) for 3 seconds for auto search. -
Page 19: Pairing Mobile Devices With The Receiver Via Bluetooth
Activate Bluetooth on your mobile device and search for available Bluetooth devices. Make a connection with “VIRE BT” device. Setup Examples PSS-106 and External Devices You can connect a range of external devices to the PSS-106: ● WM-10 Handheld Microphone for PSS-106 or BP-10 Beltpack for PSS-106 ●... -
Page 20: Multiple Pss-106
XLR/jack connectors (12) on the first PSS-106 devices. Use signal cables to connect the Line(balanced)/Mix 6,3 mm jack OUT (26) connector on the first PSS-106 devices to the Line/High impedance 6,3 mm jack CH2 (28) connector on the second PSS-106 devices. -
Page 21: Operation
Microphone Receiver and 6.7. Media Player on pages 21–23 for more information. Use PFL (Pre-Fade Listen) to set the proper input level for the audio amixer and set the main mix level. After use, switch off the PSS-106 devices. See 5.2. Switching the PSS-106 On/Off on page 17 for more information. -
Page 22: Battery Status
PSS-106 Battery Speaker 6.4. Battery Status There are 4 LED battery indicators (23) (LOW, 1, 2, 3). The LED indicators show the current battery charge level: ● LOW: < 10 % ● 1: 25–49 % ● 2: 50–75 % ●... -
Page 23: Setting Voice Priority
PSS-106 Battery Speaker Setting Voice Priority ● When the voice priority switch (19) is pressed, the device will mute other channels whenever you speak into the microphone connected to CH1 or the wireless microphone. ● When the voice priority switch (19) is released, the device’s output will not be muted whenever you speak into the microphone connected to CH1 or the wireless microphone. -
Page 24: Media Player
PSS-106 Battery Speaker Media Player Fig. 15 Connecting Auxiliary Signal Sources Use the aux signal input connector (40) to connect auxiliary signal sources. Control Modes There are 3 control modes: ● Aux Mode ● MP3 Mode (USB or SDcard) ●... -
Page 25: Bluetooth Mode
PSS-106 Battery Speaker Bluetooth Mode Attention Bluetooth can be used only for receiving of wireless audio signals. Bluetooth can only be used as a means to receive wireless audio signals. It is not possible to pair the device with other devices via Bluetooth. -
Page 26: Maintenance
PSS-106 Battery Speaker Maintenance Preventive Maintenance Attention Before each use, examine the device visually for any defects. Make sure that: ● There are no deformations on the housing. ● The power cables are not damaged and do not show any material fatigue. -
Page 27: Storage
Approval Hereby, Highlite International declares that the device PSS-106, product code D2612 and D2613, is in compliance with Directive 2014/53/EU (RED – Radio Equipment Directive). The full text of the EU declaration of conformity is available at the respective product page on the website of Highlite International (www.highlite.com). - Page 28 ©2022 DAP...
