- Page 1 PS-115A ORDERCODE D3576...
- Page 2 Congratulations! You have bought a great, innovative product from DAP Audio. The DAP Audio PS-115A brings excitement to any venue. Whether you want simple plug-&-play action or a sophisticated show, this product provides the effect you need. You can rely on DAP Audio, for more excellent audio products.
-
Page 3: Table Of Contents
DAP Audio DAP Audio PS-115A Product Guide Warning..…...................…………………………………………....Safety-instructions………………………………………………………………………………………….…....Operating Determinations……………………………………………………………………………………....Description..…................……….…………………………………....Features………………………………………………………………………………….………………….…....Overview ..…………………………………………………………………………………..……......... ControlPanel..…………………………………………………………………………………….……......Installation..............……………………………..…………………………....Set Up and Operation..............……..…………………………….……....Connection Cables......…........………..………….…….………….…....Maintenance………......…........………..………….…….………….…....Replacing the Fuse................…………………….…………………....Troubleshooting………......…........………..………….…….………….…...... Product Specifications..............……………….…….…………………..... - Page 4 Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: • DAP PS-115A • IEC cable • User manual Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
-
Page 5: Warning
WARNING CAUTION! Keep this system away from rain and moisture! SAFETY INSTRUCTIONS Every person involved with the installation, operation and maintenance of this system has to: be qualified follow the instructions of this manual CAUTION! Be careful with your operations. With a dangerous voltage you can suffer a dangerous electric shock when touching the wires! Before you initial start-up, please make sure that there is no damage caused by transportation. -
Page 6: Operating Determinations
Make sure that the available voltage is not higher than stated on the rear panel. Make sure that the power-cord is never crimped or damaged. Check the system and the power- cord from time to time. Please turn off the power switch, when changing the power cord or signal cable, or select the input mode switch. -
Page 7: Description
Description of the device Features The PS-115A is an active 15" 2-way Fullrange speakersystem: • Adjustable Line/Mic Input with Combo connector. • Treble level control • Bass level control • Master volume control with Clip-LED • Roadproof housing made of plastics •... -
Page 8: Controlpanel
Replace the fuse only with a fuse of same specification (F8A). Operation Installation Remove all packing materials from the PS-115A. Check that all foam and plastic padding is removed. Connect all cables. Always disconnect from electric mains power supply before cleaning or servicing. -
Page 9: Connection Cables
Connection Cables Take care of your cables, always holding them by the connectors and avoiding knots and twists when coiling them: This gives the advantage of increasing their life and reliability. Periodically check your cables. A great number of problems (faulty contacts, ground hum, discharges, etc.) are caused entirely by using unsuitable or faulty cables. -
Page 10: Maintenance
Maintenance The PS-115A requires almost no maintenance. However, you should keep the unit clean. Disconnect the mains power supply, and then wipe the cover with a damp cloth. Do not immerse in liquid. Keep connections clean. Disconnect electric power, and then wipe the audio connections with a damp cloth. -
Page 11: Product Specifications
Product Specifications Power supply: 230V 50/60Hz Fuse: F8A Woofer: 15" Neodymium, 4Ω, 65mm voice coil High driver: 1,35" Titanium dome, 8Ω 34mm voice coil Freq. response: 55 Hz-18 kHz Max. power Low- amp: 300Wrms in 4 Ohm Max. Power High-amp: 150Wrms in 8 Ohm SPL (1W/1M): 122,5dB dB 1W/1m Crossover Frequency: 1700 Hz Diversity (HxV): 90°... - Page 12 2009 Dap Audio.
