Module programming

Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes.
Wait until the LED turns ON solid red.
1
Note: To skip the transponder programming and use convenience features only, press
the programming button 5 times. Wait until the LED turns ON solid orange, then
proceed with step 2.
Insert and turn the key tothe ON position.
The LED will start to flash orange.
2
If the transponder programming was skipped, the LED turns ON solid orange for 3
seconds then shuts OFF when programming is done.
Make sure the vehicle cannot start:
3
Automatic transmission: Put the transmission in Driver (D Position).
-
Manual transmission: DO NOT depress the clutch pedal.
-
4
Turn and keep the key at START until the LED starts to flash green.
Turn the key back to ON.
5
The LED will start to flash green 1, 2 or 3 times and then turn OFF.
For vehicles equipped with an automatic transmission, put the transmission in Park (P
6
position).
Turn the key to OFF and remove it from the ignition barrel, when the module is
7
successfully programmed.
You have successfully completed the module programming sequence.
11
403.GM5 4.17 2005 Chevrolet Malibu Classic
