Module programming

Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes.
Wait until the LED turns ON solid red.
1
Note: To skip the transponder programming and use convenience features only, press
the programming button 5 times. When the LED turns ON solid orange, proceed to
step 2.
Insert and turn the key to the ON position. The LEDflashes orange thenturns ON solid
2
green for 3 seconds, then turns OFF. This may take up to 1 minute.
Turn the vehicle ignition OFF and remove the key once the module is successfully
3
programmed.
You have successfully completed the module programming sequence.
10
403.GM11 1.20 2009 Hummer H2
