Keysight
S9106AC-2IF and S9106AC-4UP
5G FR1 Multi-port
Transceiver Solutions
Keysight S9106AC-2IF 5G FR1 Multi-port Transceiver
contains: two Transceivers, 380 MHz to 6 GHz,
with MIMO Subsystem and 7 to 15 GHz High IF
Startup Guide
Keysight S9106AC-4UP 5G FR1 Multi-port Transceiver
contains: four Transceivers, 380 MHz to 6 GHz,
with MIMO Subsystem

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S9106AC-2IF and is the answer not in the manual?

Questions and answers

Related Manuals for Keysight Technologies S9106AC-2IF

Summary of Contents for Keysight Technologies S9106AC-2IF

  • Page 1 Startup Guide Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions Keysight S9106AC-2IF 5G FR1 Multi-port Transceiver Keysight S9106AC-4UP 5G FR1 Multi-port Transceiver contains: two Transceivers, 380 MHz to 6 GHz, contains: four Transceivers, 380 MHz to 6 GHz, with MIMO Subsystem and 7 to 15 GHz High IF with MIMO Subsystem...
  • Page 2 WARRANT THIRD-PARTY SYSTEM- computer software pursuant to the FAR LEVEL (COMBINATION OF CHASSIS, and the DFARS and are set forth © Keysight Technologies, Inc. 2021, 2022 CONTROLLERS, MODULES, ETC.) specifically in writing elsewhere in the No part of this manual may be PERFORMANCE, SAFETY, OR EULA.

  • Page 3: Table Of Contents

    3. 2. 2 Connectors, S9106AC-2IF on the Rugged Front Panel 3. 2. 3 Connectors, S9106AC-4UP on the Rugged Front Panel 3. 2. 4 Connectors, M9037A PXIe Embedded Controller 3. 2. 5 Connectors, S9106AC-2IF and S9106AC-4UP Rear Panel 3. 2. 6 Connectors, E7770A Common Interface Unit (CIU) for the S9106AC-2IF 5G FR1 Multi-port Transceiver 3. 2. 6. 1 Connectors, E7770A-LA2 CIU LO Card 3.
  • Page 4 6. 1 Verify X-Apps Software Controls an S9106AC-2IF 6. 1. 1 Verify X-Apps Controls S9106AC-2IF RF Ports at 3 GHz 6. 1. 2 Verify X-Apps Controls S9106AC-2IF High IF Ports at 10 GHz 6. 2 Verify X-Apps Software Controls an S9106AC-4UP 6.

  • Page 5: Overview

    In this document... This document describes the installation process to start up and prepare the Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions. 1. Review this Overview Review Safety Requirements on page 3 Review Hardware on page 21 Install Hardware on page 35 Install Software on page 43 Verify Operation on page 45 MIMO on page 57 Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
  • Page 6 Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...

  • Page 7: Review Safety Requirements

    Do not proceed beyond a WARNING notice until the indicated conditions are fully understood and met. Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...

  • Page 8: Safety

    Voltage Directive) as well as current editions of the following standards (dates and editions are cited in the Declaration of Conformity): IEC/EN 61010-1 2. 2. 2 Acoustic Statement (European Machinery Directive) Acoustic noise emission LpA <70 dB Operator position Normal operation mode per ISO 7779 Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
  • Page 9 AC Mains because it serves as a ground and helps protect the chassis and modules from electrostatic damage. Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...

  • Page 10: Weight And Dimensions

    Weight: 18.1 kg (40 lbs) 2. 4 Handling and Lifting Use both side handles when lifting the S9106AC Base System or E7770A Common Interface Unit (CIU). Use a rolling cart when transporting the S9106AC Base System or E7770A Common Interface Unit (CIU). Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...

  • Page 11: Cleaning

    Flush spill area with water. Dispose of isopropyl alcohol in accordance with all applicable federal, state, and local environmental regulations. In case of fire, use alcohol foam, dry chemical, or carbon dioxide; water may be ineffective. Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...

  • Page 12: Environmental Conditions (Operating)

    The Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions are designed for use in the following conditions: For indoor use only Altitude up to 6,561.68 ft (2,000 m) Operating Temperature 10 to 40° C, Maximum Relative Humidity (non-condensing): 95% RH Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...

  • Page 13: Ventilation

    Do NOT block vents and fan exhaust: To ensure adequate cooling and ventilation, leave a gap of at least 50 mm (2") around vent holes on both sides of the chassis. Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...

  • Page 14: Location And Mounting

    Consider ergonomics when locating any keyboard or mouse which will be used in connection with an instrument. Install the Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions so that the detachable power cords are readily identifiable and is easily reached by the operator. The detachable power cord is the disconnecting device.

  • Page 15: Power Requirements

    This instrument has auto-ranging line voltage input. Before switching on the instrument, be sure the supply voltage is within the specified range and voltage fluctuations do not exceed 10 percent of the nominal supply voltage. Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
  • Page 16 2. 9. 4 Do Not Use Extension Cords DO NOT use extension cords to power your equipment. 2. 9. 5 Do Not Use Converters or Adapters DO NOT use any converters or adapters. Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
  • Page 17 2. 9. 7 Avoid Loose Connection DO NOT use outlet if the power cord makes a loose connection. 2. 9. 8 Make Proper Connection DO NOT allow plug to bend down or become loose. Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...

  • Page 18: Battery Replacement On The M9037A Controller

    For exact should change the battery range information, refer to the battery after 3 to 4 years of ser- manufacturer’s specifications. vice. See the Data Sheet for the Keysight M9037A, 5991-3661EN. Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...

  • Page 19: Ac Power Cord

    2. 11 AC Power Cord The Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions are equipped with three-wire power cords, in accordance with international safety standards. These power cords ground the Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions cabinet when connected to an appropriate power line outlet.

  • Page 20: Protecting Against Electrostatic Discharge (Esd)

    Additional Information About ESD For more information about ESD and how to prevent ESD damage, contact the Electrostatic Discharge Association (http://www.esda.org). The ESD standards developed by this agency are sanctioned by the American National Standards Institute (ANSI). Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...

  • Page 21: Front And Rear Panel Symbols

    2 Review Safety Requirements 2. 13 Front and Rear Panel Symbols Symbols that may be on the exterior of S9106AC-2IF and S9106AC-4UP hardware components are: Symbol Description This symbol is used to indicate power ON and to mark the position of the instrument power line switch.
  • Page 22 GB 18455-2001 as required by the China RoHS regulations for paper/fiberboard packaging. The CSA mark is a registered trademark of the CSA International. This symbol indicates that anti-static precautions should be taken. This symbol indicates earth ground. This mark designates Direct Current. Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...

  • Page 23: Returning For Service

    “FRAGILE”. 5. On the shipping label, write ATTENTION REPAIR DEPARTMENT and the RMA number. In your correspondence, refer to the system by serial number. Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
  • Page 24 Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...

  • Page 25: Review Hardware

    Before installing hardware or software, review the following hardware components: Hardware Components on page 22 Connector Descriptions on page 23 Connectors, 10 MHz Ref In/Out on the Rugged Front Panel on page 23 Connectors, S9106AC-2IF on the Rugged Front Panel on page 24 Connectors, S9106AC-4UP on the Rugged Front Panel on page 25 Connectors, S9106AC-2IF and S9106AC-4UP Rear Panel on page 28 Connectors, E7770A Common Interface Unit (CIU) for the S9106AC-2IF 5G FR1 Multi-port Transceiver on page 30 Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...

  • Page 26: Hardware Components

        two M9410A PXIe VXT Vector Transceivers) one E7770A Common Interface Unit (CIU) with     two E7770A-HB2 CIU Channel Card, 7 to 15 GHz High IF     one E7770A-LA2 CIU LO Card     one E7770A-LD2 CIU LO Distribution Card The S9106AC-2IF, two-channel configuration, consists of two transceivers providing two RF Tx channels, two RF Rx channels, or two High IF Tx and Rx channels operating in one frequency range at a time: FR1 RF frequencies ranging from 380 MHz to 6 GHz or High IF frequencies from 7 to 15 GHz Keysight S9106AC-4UP 5G FR1 Multi-port Transceiver on page 40...

  • Page 27: Connector Descriptions

    1 to 110 MHz.) Connector BNC (f) Frequency 1 MHz to 110 MHz, sine wave Lock range ± 1 ppm, nominal Amplitude 0 to 10 dBm, nominal Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...

  • Page 28: Connectors, S9106Ac-2If On The Rugged Front Panel

    3 Review Hardware 3. 2. 2 Connectors, S9106AC-2IF on the Rugged Front Panel CIU DUT Interconnect IF Out Connector Type-N (f), 50 Ω, nominal Frequency Range 7 to 15 GHz IF In Connector Type-N (f), 50 Ω, nominal Frequency Range 7 to 15 GHz RF Transceiver .380 - 6 GHz...

  • Page 29: Connectors, S9106Ac-4Up On The Rugged Front Panel

    Trig 1 and Trig 2 (Input or Output, Selectable) Connectors BNC (f) Input Impedance 1 kΩ or 50 Ω, nominal Input Level Range –3.3 V to +3.3 V Output Impedance 50 Ω, nominal Output Level Range 3.3 V LVTTL Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...

  • Page 30: Connectors, M9037A Pxie Embedded Controller

    PXI backplane GPIB Connector GPIB (Micro-D 25-pin) PCIe Connector x8 Gen 3 PCIe IPASS connector for controlling a second PXIe or AXIe chassis or RAID storage Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
  • Page 31 For exact change the battery after 3 range information, refer to the battery to 4 years of service. manufacturer’s specifications. See the Data Sheet for the Keysight M9037A, 5991-3661EN. Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...

  • Page 32: Connectors, S9106Ac-2If And S9106Ac-4Up Rear Panel

    3 Review Hardware 3. 2. 5 Connectors, S9106AC-2IF and S9106AC-4UP Rear Panel AC Line Input (Use the AC line cord supplied with the S9100A.) Connector, Three-Prong 100/120 V, 50/60 Hz, 1200 W MAX (Lower range) 220/240 V, 50/60 Hz, 1300 W MAX (Upper range)
  • Page 33 PXI_CLK10_IN and OUT signals from the System Timing Module. To provide a 10 MHz Clock to the S9100A, Connectors, 10 MHz Ref In/Out on Rugged Front Panel on page 23. For additional information, see the Data Sheet for the Keysight M9019A, 5992-1481EN. Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...

  • Page 34: Connectors, E7770A Common Interface Unit (Ciu) For The S9106Ac-2If 5G Fr1 Multi-Port Transceiver

    CLK In Connector SMA (f), 50 Ω, nominal (Intended for future use.) LO Out Connector SMA (f), 50 Ω, nominal This connector supplies the local oscillator output for use with a second (independent) LO source. Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...

  • Page 35: Connectors, E7770A-Ld2 Ciu Lo Distribution Card

    Auxiliary local oscillator output 4. LO In 2 Connector SMA (f), 50 Ω, nominal Input source used in configurations with multiple E7770A CIUs; this connection would be from the LO Card LO Out of a second E7770A CIU. Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...

  • Page 36: Connectors, E7770A-Hb2 Ciu Channel Card, 7 To 15 Ghz High If

    DL IF input for Channel B. DUT IF In/Out B Connector SMA (f), 50 Ω, nominal In/Out connection for Channel B. IF Out B Connector Type-N (f), 50 Ω, nominal UL IF output for Channel B. Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...

  • Page 37: Connectors, E7770A Ciu Rear Panel

    The E7770A CIU rear panel contains the connectors for up to eight Channel Cards; each rear panel Channel Card (labeled: 1A, 1B, 2A, 2B, 3A, 3B, 4A, 4B) corresponds to a Channel Card available from the front of the E7770A CIU. In the S9106AC-2IF 5G FR1 Multi-port Transceiver configuration, only rear panel connectors for CHANNEL 1A and CHANNEL 1B are usable with the E7770A-HB2 CIU Channel Card,...

  • Page 38: Connectors, E7770A Ciu Rear Panel, Controller Card

    BNC (f), 50 Ω, nominal Input Level Range 5 V TTL (See description for TRIG 1.) Ctrl 1 Connector Micro-HDMI Reserved for Keysight internal use only. Ctrl 2 Connector Micro-HDMI Reserved for Keysight internal use only. Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...

  • Page 39: Install Hardware

    FR1 RF frequencies ranging from 380 MHz to 6 GHz or High IF frequencies from 7 to 15 GHz Keysight S9106AC-4UP 5G FR1 Multi-port Transceiver on page 40, four-channel configuration, consists of four RF transceivers providing four RF Tx channels or four RF Rx channels, operating in one frequency range at a time: FR1 RF frequencies ranging from 380 MHz to 6 GHz Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...

  • Page 40: Keysight S9106Ac-2If 5G Fr1 Multi-Port Transceiver

    4 Install Hardware 4. 2 Keysight S9106AC-2IF 5G FR1 Multi-port Transceiver Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
  • Page 41 SMA (m) to Type-N (m), 1100 mm (43.3 in)       Transceiver 1, CIU RF Interconnections Connect E7770A-HB2 CIU CHANNEL 1A, DUT IF OUT (rear panel) to S9106AC-2IF labeled: "From DUT IF Out" (front panel). Connect E7770A-HB2 CIU CHANNEL 1B, DUT IF IN (rear panel) to S9106AC-2IF labeled: "To DUT IF In" (front panel).

  • Page 42: Connect Cables, Lan Cables, A Display, A Keyboard & Mouse

    2. Connect LAN 1 (top) to the Site LAN at your facility. ➅ 3. Connect LAN 2 (bottom) to the E7770A CIU CONTROL (rear panel). 4. Connect a Display, Keyboard & Mouse (Not included with S9106AC-2IF). Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...

  • Page 43: Connect Ac Power Cords & Power On Equipment

    1. Power on the E7770A CIU Rear Mains Switch, located on the rear panel. 2. Power on the E7770A CIU AC Power Switch, located on the left front panel. 3. Power on the S9106AC-2IF AC Power Switch, located on the right front panel. Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...

  • Page 44: Keysight S9106Ac-4Up 5G Fr1 Multi-Port Transceiver

    RF loop-back cable with adapters (or equivalent) can be used:       one 5063-1530 RF Cable, SMA (m) to SMA (m), 152.4 mm (6.0 in)       two 1250-1250 Adapters, SMA (f) to Type-N (m) Remove this loop-back cable from all RF ports and HD ports during normal use. Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...

  • Page 45: Connect A Lan Cable, A Display, A Keyboard & Mouse

    4. 3. 1 Connect a LAN Cable, a Display, a Keyboard & Mouse 1. Connect LAN 1 (top) to the Site LAN at your facility. 2. Connect a Display, Keyboard & Mouse (Not included with S9106AC-2IF). 4. 3. 2 Connect AC Power Cord & Power On Equipment Power on the S9106AC-4UP AC Power Switch, located on the right front panel.
  • Page 46 Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...

  • Page 47: Install Software

    5 Install Software 5 Install Software The S9106AC-2IF and S9106AC-4UP are configured with an M9037A PXIe Embedded Controller and all required software is pre-installed at the factory. Proceed to Verify Operation on page 45. Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
  • Page 48 Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...

  • Page 49: Verify Operation

    S9106AC Base System; they both power on and initialize automatically when the S9106AC Base System is powered on. Verify X-Apps Controls S9106AC-2IF RF Ports at 3 GHz on page 46 Verify X-Apps Controls S9106AC-2IF High IF Ports at 10 GHz on page 50 To verify operation of the S9106AC-4UP 5G FR1 Multi-port Transceiver Power on the S9106AC Base System The M9037A PXIe Embedded Controller and the M9300A PXIe Reference...

  • Page 50: Verify X-Apps Software Controls An S9106Ac-2If

    S9106AC-2IF 5G FR1 Multi-port Transceiver contains two M9410A PXIe VXTs that are labelled on the Rugged Front Panel as Transceiver 1 and Transceiver 2. 6. 1. 1 Verify X-Apps Controls S9106AC-2IF RF Ports at 3 GHz This process verifies operation of RF Transceiver .380 - 6 GHz, RF Out ➀...
  • Page 51 Each Mode runs within a screen (there can be multiple screens). Screens are shown as tabs across the top of the interface. IQ Analyzer Mode is included with the S9106AC-2IF and appears as a tab with the label IQ Analyzer 1.
  • Page 52 Select Input/Output from the drop-down menu panel (top-right corner), select RF Source tab, select RF Output Port drop-down menu, and select RF Output. b. Set RF Power to –10 dBm, Frequency to 3 GHz, and RF Output to On. Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
  • Page 53 RF In ➁ RF Transceiver .380 - 6 GHz, of the S9106AC-2IF are working properly. (The power level is only approximate because there is loss in the cable being used and this loss is not being corrected during the measurement.)

  • Page 54: Verify X-Apps Controls S9106Ac-2If High If Ports At 10 Ghz

    6 Verify Operation 6. 1. 2 Verify X-Apps Controls S9106AC-2IF High IF Ports at 10 GHz This process verifies operation of the RF Transceiver 7 - 15 GHz, RF Out ➃ RF In ➄ located on the Rugged Front Panel; these connectors may be referred to as: "High IF" or "DUT IF".
  • Page 55 Select Input/Output from the drop-down menu panel (top-right corner), select RF Source tab, select RF Output Port drop-down menu, and select DUT IF OUT 1. b. Set RF Power to –10 dBm, Frequency to 10 GHz, and RF Output to On. Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
  • Page 56 RF In ➄ RF Transceiver 7 - 15 GHz, of the S9106AC-2IF are working properly. (The power level is only approximate because there is loss in the cable being used and this loss is not being corrected during the measurement.)

  • Page 57: Verify X-Apps Software Controls An S9106Ac-4Up

    This loop-back cable is not included with the S9106AC-4UP 5G FR1 Multi-port Transceiver. Use a cable with two adapters (or equivalent) such as:       one 5063-1530 RF Cable, SMA (m) to SMA (m), 152.4 mm (6.0 in) and       two 1250-1250 Adapters, SMA (f) to Type-N (m) Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
  • Page 58 3. Select the IQ Analyzer 1 drop-down selector. 4. Set the Mode / Measurement / View for IQ Analyzer 1: a. Select Mode as IQ Analyzer (Basic). b. Select Measurement as Complex Spectrum. c. Select View as Normal. d. Select OK. Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
  • Page 59 Select Input/Output from the drop-down menu panel (top-right corner), select RF Source tab, select RF Output Port drop-down menu, and select RF Output. b. Set RF Power to –10 dBm, Frequency to 3 GHz, and RF Output to On. Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...
  • Page 60 RF Transceiver .380 - 6 GHz, of the S9106AC-4UP are working properly. (The power level is only approximate because there is loss in the cable being used and this loss is not being corrected during the measurement.) Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions, Startup Guide...

  • Page 61: Mimo

    All of the previous sections must be completed before performing MIMO measurements with the S9106AC-2IF or the S9106AC-4UP. To set up and run MIMO on the S9106AC-2IF or the S9106AC-4UP Refer to the Keysight MIMO Measurement Guide, M9410-90016 for the Keysight M9410A/M9411A VXT PXIe Vector Transceiver For DUT IF MIMO measurements, select the DUT IF ports.
  • Page 62 Documentation is updated periodically. For the latest information about these products, including instrument software upgrades, application information, and product information, browse to one of the following URLs, according to the name of your product: Keysight S9106AC-2IF and S9106AC-4UP 5G FR1 Multi-port Transceiver Solutions www.keysight.com/find/s9100a Keysight M9019A PXIe Chassis: 18-slot, 3U, 24 GB/s, Gen 3...
