CHARACTERISTICS:

The HD67627-A1 is S7comm / EtherNet/IP Slave - Converter.
It allows for the following characteristics:
Isolation between Ethernet - Power Supply;
Two-directional information between EtherNet/IP bus and S7comm bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8...24V AC or 12...35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].

CONFIGURATION:

You need Compositor SW67627 software on your PC in order to perform the following:
Define the parameters of EtherNet/IP line;
Define the parameters of S7comm line;
Define the S7comm requests to send to the S7comm servers;
Update the device.
