2. Specifications

2.1.

Core System

CPU
Cache
Memory
Embedded BIOS
Chipset
2.2.

Expansion Busses

PCI Express
Other
Specifications
Intel® Xeon® processor D, Pentium® D processor (formerly "Broadwell-DE")
•
Intel® Xeon® D1539 1.6/1.9 GHz 35W (8C, up to 2133MHz) (eTEMP)
•
Intel® Xeon® D1519 1.5/1.8 GHz 25W (4C, up to 2133MHz) (eTEMP)
•
Intel® Xeon® D1548 2.0/2.3 GHz 45W (8C, up to 2400MHz)
•
Intel® Xeon® D1527 2.2/2.5 GHz 35W (4C, up to 2133MHz)
•
Intel® Pentium® D1508 2.2/2.5 GHz 25W (2C, up to 1866MHz)
•
Intel® Xeon® D1559 1.5/1.8 GHz 45W (12C, up to 2133MHz) (eTEMP)
•
Intel® Xeon® D1577 1.3/1.6 GHz 45W (16C, up to 2400MHz)
Note: D1559, D1577 are supported by project basis. Please contact local sales.
Supporting: Intel® VT (including VT-x, VT-d, VT-x with Extended Page Tables), Intel® HT
Technology, Intel® SSE4.2, Intel® 64 Architecture, Intel® Turbo Boost Technology 2.0,
Intel® AVX2, Intel® TSX-NI, Intel® Platform Protection Technology with Intel® TXT and
Execute Disable Bit, Intel® Data Protection Technology with Intel® Secure Key and Intel®
AES-NI
Note: Availability of features may vary between processor SKUs.
24MB for D1577, 18MB for D1559, 12MB for D1548/D1539, 6MB for D1527/D1519,
3MB for D1508
Dual channel ECC (or non-ECC) 1866/2133/2400 MHz DDR4 memory up to 32GB in dual
stacked SODIMM sockets
Note: Supported memory frequencies may vary between processor SKUs.
AMI EFI with CMOS backup in 16MB SPI BIOS
Integrated in SoC
16 PCI Express Lanes Gen3 (CD):
Lanes 16-31 (four controllers, can be configured to 1 x16, 2 x8 or 4 x4/x2/x1)
8 PCI Express Lanes Gen3 (AB):
Lanes 8-15 (two controllers, can be configured to 1 x8 or 2 x4/x2/x1)
Up to 8 PCI Express Lanes Gen2 (AB/CD):
Lanes 0-7 (two controllers defined by PICMG, can be configured to x4, x2, x1)
Notes:
•
PCIe lane 7 is supported by build option, in place of GbE
•
Although Broadwell-DE platform supports eight roots on Lanes 0-7, the PICMG COM.0
R3.0 specification for Lanes 0-7 states: "Type7 module may support eight x1 root hubs.
It is expected that future generation products may limit the number of available root
hubs."
•
LPC bus
•
SMBus (system)
•
2
I C (user)
