Features
button ( )
REVIEW
l
/MARK
This is used to review recorded data the trip directly on the display, to reset the
min/max data on the display and to stop the unit.
It is also used to place an inspection mark in the data.
button ( )
Channel
l
This button is used to manually switch the channels shown on the display.

Display and LED

The extra large display shows current, minimum and maximum temperatures and if
alarm events have occurred for the current day and up to 29 days in the past. Details of
any alarm event can be checked by inspecting the statistics history on the logger's
display or in more detail via Control Solutions VTMC. In addition, a red Alarm LED
shows if an alarm event has occurred.

External Probes

The VFC400-USB will accept external probes from the ST100 product range.

Power Supply

The same USB socket that is used for communication is also used for providing power to
the VFC400-USB, using an external 5V USB power supply. The AAA batteries maintain
all functionality when USB power is not connected. A long-life CR2032 lithium backup
battery maintains essential functions if the AAA batteries are empty and external power
is not supplied.

PDF

The VFC400-USB will generate a detailed PDF report when plugged into a USB port of a
PC. The PDF report shows a summary of the trip, presents the data in chart and list
format and also includes a day summary page, showing an overview of the statistics
collected. A CSV file of the data list is also available.
VFC400-USB User Guide 8
