Interpreting the Data
Marked readings
In the data list, each entry may be marked with one or more of the following symbols:
A + symbol will be shown, if the VFC400-USB was downloaded with Control
l
Solutions VTMC.
A * symbol will be shown if an inspection mark was placed with the
l
button.
A $ symbol will be shown when the Paused feature was enabled, and any button
l
was pressed during recording.
A # symbol will be shown where a reading could not be taken due to USB
l
communication with a PC.
A % symbol will be shown when the min/max readings of either channel were
l
reset. You will need to identify the channel that was reset in the chart.
Symbols are shown against the reading following the event.
Legend
Shows the symbols for
appear in the readings.
Page information
The current page number and the total number of pages appear on every page.
VFC400-USB User Guide
download marks, inspections marks
REVIEW
and paused marks if they
58
/MARK
