Chapter 1
FCC Rules. These limits are designed to provide reasonable
Note
protection against harmful interference when the equipment is
operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction
manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the
user will be required to correct the interference at their
expense.
Contact ISS Canada
Please contact ISS Canada with any questions or concerns about the RTMS or other ISS
Canada products, toll free at 1-800-668-9385. More information about our complete product
line is available on the web at www.imagesensingca.com.
Brief Description
The RTMS (Remote Traffic Microwave Sensor) measures the distance to objects in the path of
its microwave beam. This ranging capability allows it to detect moving and stationary vehicles
in multiple detection zones.
A single sensor can monitor traffic in up to 8-12 lanes. The sensor can be mounted on road-
side poles and aimed at a right angle to the road; this is referred to as the side-fired
configuration.
The internal processor calculates volume, occupancy, average speed and vehicle classifications
for each lane and transmits the information using its data ports and communication interfaces.
Optional contact closure outputs are also available for compatibility with loop based systems.
•
•
Caution
•
Consult ISS Canada before using the RTMS or other RTMS-related
products for any purpose not expressly described in this manual or any
other RTMS product manual. Do not use the RTMS to control or
Warning
operate a gate-opening mechanism. Use of the RTMS for any
unauthorized purpose may cause injury to personnel or damage to
equipment.
G4 User Manual
For optimal accuracy, ISS Canada strongly recommends using ISS
Canada-trained personnel to install all RTMS-related products.
ISS Canada also strongly recommends using ISS Canada-trained
personnel to survey installation sites for all RTMS-related products.
For more information about our installation, surveying, and training
programs, contact ISS Canada at 1-800-668-9385.
About the G4 System
© 2009 ISS Canada.
1-3
