RTMS G4 Installation
Mounting and Aiming Procedure
Installation ISS Canada hardware may require that you work above the
ground on a ladder or bucket truck. Please make sure you have all the
required equipment and are aware of potential safety issues before
Warning
starting any installation. DO NOT install any RTMS hardware if you
are unsure how to complete the installation or lack appropriate safety
equipment. ISS Canada does not recommend installing this hardware
during inclement weather.
The following equipment is required to mount and aim the RTMS unit:
•
Provided By ISS Canada. RTMS unit and its housing.
•
Not Provided. Bolts or stainless steel banding. The bolt specifications depend on the
mounting requirements: for example, different bolts may be required when the RTMS unit
is mounted on a wooden pole than when the RTMS unit is mounted on a concrete wall.
•
Provided By ISS Canada. Lynch pin
•
Not Provided. 7/16" wrench, 1/2" wrench, assorted tools to be determined by mounting
specifications.
To mount and aim the RTMS unit:
1. Attach the bracket to the roadside pole (or another specified location) using bolts or
stainless steel banding.
2. Secure the RTMS to the mounting bracket by inserting the lynch pin.
3. Aim the RTMS as indicated on the diagram above. A 7/16" wrench is required to
release/tighten the ball-joint bolt.
4. Adjust the RTMS to be perpendicular to the travel lanes and level side to side.
5. Look from behind the unit and use the top sight-ridge as a guide to align the bore sight.
6. Tilt so that the top of the RTMS is aimed to the first 1/3 of the monitored lanes.
7. Secure the position by tightening the bolt.
