Chapter 3
How to Modify or Troubleshoot the Connection with the RTMS
Hardware
The Communications Screen allows you to troubleshoot data connections if you encounter a
problem making a data connection on startup. You can also use these options to reconfigure
communication parameters as needed throughout the product life-cycle.
The basic communication options screen:
1. Use the basic communication screen to accomplish the following:
−
Change the WinRTMS Utility communication parameters such as the mode from
Single RTMS (Direct) to Multiple Sensors (Multidrop).
−
Search for Sensors by first using the default port (and parameters) before making any
changes. During the search for Multiple Sensors, several sensors may be found. In this
case their Sensor ID numbers will be displayed, allowing polling of all of them or a
Selected Range of IDs as well as focusing on a single sensor ID.
2. Click the Communication button to display advanced communication parameters in both
panels:
