G4 Software

RTMS Zone Options

This screen allows you to alter lane number and other related parameters such as beeping and
traffic direction. See How to Fix Splashing.
Options are:
•
Lane Numbers. A list of lane numbers is displayed.
−
Once a Lane Number is selected (highlighted), you can:
Re-number the lanes.
Change vehicle icon direction
Turn on a Beep upon detection in that lane (Zone).
This is an additional aid in verifying that vehicles you see on the road are
detected properly by the RTMS and reported in the correct Zones.
•
Fine Tune. If you observe "Splashing" where a single vehicle also shows detection in an
adjacent zone or if vehicles are shown in the wrong lane, this may indicate that the zone
boundary positions do not line up with the lanes. Make sure that the splashing was not
caused by a vehicle changing lanes before using the Fine Tune option.
•
Labeling. Rename lanes with this option.
•
OK. Saves changes and returns to the main screen.
•
Cancel. Returns to the main screen without saving changes.
