M220 Series
Multi-Output Access Control
Power Supply/Chargers
Installation Guide
Models Include:
AL300M220
- 2.5A @ 12VDC or 24VDC.
AL600M220
- 6A @ 12VDC or 24VDC.
AL1024M220
- 10A @ 24VDC.
For a red enclosure add an "R" suffix to the part #, e.g. AL300MR220
Rev. 111103
AL400M220
- 4A @ 12VDC or 3A @ 24VDC.
AL1012M220
- 10A @ 12VDC.
More than just power.
TM
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Altronix AL600M220
Summary of Contents for Altronix AL600M220
-
Page 1: Installation Guide
Installation Guide Models Include: AL300M220 AL400M220 - 2.5A @ 12VDC or 24VDC. - 4A @ 12VDC or 3A @ 24VDC. AL600M220 AL1012M220 - 6A @ 12VDC or 24VDC. - 10A @ 12VDC. AL1024M220 - 10A @ 24VDC. For a red enclosure add an “R” suffix to the part #, e.g. AL300MR220 More than just power. -
Page 2: Specifications
Overview: Altronix M220 Series multi-output access control power supply/chargers are specifically designed for use with access control systems and accessories. These units convert a 220VAC (working range 198VAC - 256VAC), 50/60Hz input into five (5) individually protected 12VDC or 24VDC outputs (see specifications). Each output will route power to a variety of access control hardware devices including Mag Locks, Electric Strikes, Magnetic Door Holders, etc. -
Page 3: Installation Instructions
(pgs. 11 & 12) 2. Set output voltage: AL300M220, AL400M220 (Fig. 1c, pg. 5) and AL600M220 (Fig. 2c, pg. 6): set desired DC output voltage by setting switch SW1 to the appropriate position on the power supply board. AL1012M220 is 12VDC only. AL1024M220 is 24VDC only. -
Page 4: Maintenance
Maintenance: Unit should be tested at least once a year for the proper operation as follows: Output Voltage Test: Under normal load conditions the DC output voltage should be checked for proper voltage level (Output Voltage and Stand-by Specification Charts, pg. 4). Battery Test: Under normal load conditions check that the battery is fully charged, check specified voltage at the battery terminals and at the board terminals marked [–... -
Page 5: Output Voltage And Stand-By Specification Charts
Stand-by = 3.0A Stand-by = 1.0A Stand-by = 300mA Battery Alarm = 3.0A Alarm = 3.0A Alarm = 3.0A AL600M220 Switch 4 hr. of Stand-by & 24 hr. of Stand-by & 60 hr. of Stand-by & Output Position 5 Minutes of Alarm... - Page 6 Fig. 1 - AL300M220 and AL400M220 CAUTION: De-energize unit prior to servicing. For continued protection against risk of electric shock and fire hazard replace fuses with the same type and rating (see marking on the board). Do not expose to rain or moisture. Wire Strap (from Enclosure to Door)
- Page 7 Fig. 2 - AL600M220 CAUTION: De-energize unit prior to servicing. For continued protection against risk of electric shock and fire hazard replace fuses with the same type and rating (see marking on the board). Do not expose to rain or moisture.
- Page 8 Fig. 3 - AL1012M220 CAUTION: De-energize unit prior to servicing. For continued protection against risk of electric shock and fire hazard replace fuses with the same type and rating. Do not expose to rain or moisture. Ground Lug Wire Strap (from Enclosure to Door) BAT FAIL NC C NO NC C NO AC FAIL...
- Page 9 Fig. 4 - AL1024M220 CAUTION: De-energize unit prior to servicing. For continued protection against risk of electric shock and fire hazard replace fuses with the same type and rating (see marking on the board). Do not expose to rain or moisture. Ground Lug Wire Strap (from Enclosure...
-
Page 10: Power Fail
AL300M220 - 12VDC/24VDC @ 2.5A to MOM5 board. AL400M220 - 12VDC @ 4A or 24VDC @ 3A to MOM5 board. + DC – AL600M220 - 12VDC/24VDC @ 6A to MOM5 board. AL1012M220 - 12VDC @ 10A to MOM5 board. AL1024M220 - 24VDC @ 10A to MOM5 board. -
Page 11: Typical Application Diagrams
- DC INPUT+ DC VOLTAGE INPUT FROM FACP SIGNALING OUTPUT OR ACCESS (--) MOM5_S CONTROL DEVICE MOM5_S ALTRONIX CORP. ALTRONIX CORP. BROOKLYN, NY 11220 BROOKLYN, NY 11220 MADE IN USA MADE IN USA EOL 2.2K N.O. INPUT FROM FACP OR ACCESS... - Page 12 Typical Application Diagrams (cont’d): Fig. 8 MOM5 module shown with with wet and/or dry MOM5 module shown with with wet and/or dry normally open fire alarm trigger inputs normally closed fire alarm trigger inputs (Latching with Manual Reset): (Latching with Manual Reset): DC VOLTAGE INPUT DC VOLTAGE INPUT FROM FACP...
- Page 13 AL1024M220 Battery Size Calculation Worksheet. AL1024M220 internal current consumption (stand-by) 0.13A Load current consumption (stand-by) Stand-by time required (hours) Battery capacity required for stand-by (A+B)*C AL1024M220 internal power consumption (Alarm) 0.13A Load current consumption (Alarm) Alarm duration (Alarm) (Hours, example: 15 Min = 0.25 Hour) Battery capacity required for Alarm (E+F)*G Total calculated battery capacity...
- Page 14 Notes: - 14 - M220 Series...
- Page 15 Enclosure Dimensions (H x W x D) for: AL300M220 • AL400M220 • AL600M220 13.5” x 13” x 3.25” (342.9mm x 330.2mm x 82.6mm) 1.40” 4.85” 4.85” 1.40” (36mm) (123mm) (123mm) (36mm) 1.20” (31mm) 3.25” (83mm) 12.5” (318mm) 1.20” 1.20” 0.75”...
- Page 16 (38.1mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER II M220 Series D17R...
