SPECIFICATIONS AND HARDWARE INFORMATION
Radio Protocol Battery State
WCDMA Band 1 Battery Charging
(1922 MHz) in Constant
Current Mode
LTE Band 7 Battery Charging
(2535 MHz) in Constant
Current Mode
POE Only 56VDC
WCDMA Band 1 Battery Full Chg
(1922 MHz) (4.04 VDC)
LTE Band 7 Battery Full Chg
(2535 MHz) (4.04 VDC)
WCDMA Band 1 Battery Charging
(1922 MHz) in Constant
Current Mode
LTE Band 7 Battery Charging
(2535 MHz) in Constant
Current Mode

Connectors and LEDs

Note: Some features are available only on select models.
Item Description
Connectors
Power 5 Volt power jack.
Ethernet RJ45 Ethernet jack. For PoE models, used for power over Ethernet.
Reset Reset button. Reboots device or restores factory defaults. Refer to
details.
WPS Reserved for future use.
SIM Cellular models only. Micro (3FF) SIM slot. Refer to Installing SIM Card for details.
10
Cellular Average
Call Box Measured
Connectio Current at
n, No Data Maximum
Power
197 mA 350 mA
200 mA 387 mA
47 mA 133 mA
42 mA 146 mA
149 mA 240 mA
149 mA 267 mA
®
Conduit AP MTCAP2-868 and MTCAP2-L4E1-868 Hardware Guide
TX Pulse (AVG) Total Inrush
Amplitude Charge
Current for Measured in
GSM850 or Millicoulombs
Peak Current
for HSDPA/LTE
380 mA 0.142 mC
400 mA 0.142 mC
200 mA 0.753 mC
220 mA 0.753 mC
276 mA 0.156 mC
348 mA 0.156 mC
Resetting the Device
Total
Inrush
Charge
Duration
During
Power Up
7.07 mS
7.07 mS
6.8 mS
6.8 mS
16.2 mS
16.2 mS
